Hand tools Hand tools

Thread repair Thread repair

844 Stud extractor set 842 AIG Universal thread repair tool kit

1
Made in Germany 8 / • For outside thread 4–13 mm ( ⁄12″ – ⁄2″) and inside thread 5–12 mm
5
1
13
• Plastic box 165-S (1/9) ( ⁄64″ – ⁄2″)
• Safety-Insert-System, 2-component soft foam insert.
Insert also suitable for HAZET Assistent • Application: Repairing right-hand and left-hand threads
• Surface: chrome-plated, polished (all forms of metric and non-metric threads)
• Simple and quick fixation due
to knurled screw
• Also for aluminium threads
• 1 tool for outside threads
• 2 tools for inside threads
• Protective covers for
aluminium threads

844 • 8
844-6 • 844-7 • 844-8 • 844-10 • 844-12 1 è 4

1 L x W x H è 4 842 AIG-1/4 4 153428
mm
844/5 185 x 153 x 52 5 035878
842 N Thread repair set
842 AG Universal thread repair tool • Thread reinforcement of materials presenting a low shearing resistance.
Application in machine construction, automotive engineering,
electrical and medical engineering, for example
1
5
• For thread diameters 4 – 13 mm ( ⁄32″ – ⁄2″)
• Chrome-nickel stainless steel provides good
inside threads resisting the influences
• Application: Repairs right-hand and left-hand threads (observe direction of of weathering and corrosion
rotation) • Plastic box
All forms of metric and non-metric threads (60° flank measurement)
• Quick fixation due to adjusting screw
• Blade automatically adapts to any
thread pitch within range

1 R 4
1
5
842 AG-1 4 – 13 mm / ⁄32″ – ⁄2″ 140718
5
• For thread diameters 16 – 38 mm ( ⁄8″ – 1. ⁄2″)
1
• Application: Trimming right-hand and left-hand threads
(observe direction of rotation)
all forms of metric and non-metric threads (60° flank measurement)
• Quick fixation due to adjusting screw
• Blade automatically adapts to any
thread pitch within range

1 è 4

• 118-piece set ∙ M6 to M14
• M14 especially for spark plug thread
• Contents:
25 threaded inserts each
M6 x 1 mm x 9 mm
M8 x 1.25 mm x 12 mm
M10 x 1.5 mm x 15.0 mm
• 10 threaded inserts M12 x 1.75 mm x 18 mm
• 5 threaded inserts each
M14 x 1.25 mm x 8.4 mm
M14 x 1.25 mm x 12.4 mm
1 R 4 • 4 twist drills, 5 thread cutters, 5 assembly tools, 4 pin breaking tools
M14 x 1.25 mm x 16.4 mm
842 AG-3 16 – 38 mm / ⁄8″ – 1. ⁄2″ 149230 842 N-614/118 118 167272
1
5
