Hand tools

Thread repair

849 Tap and die set

Made in Germany /
• High performance thread cutter made of HSS steel
• Application: Problem-free rethreading even in areas with restricted access
• Operation with reversible ratchet
• Plastic box 165-L (1/3)
• Safety-Insert-System, 2-component soft foam insert.
Insert also suitable for HAZET Assistent
• Tap and die set, contents:
849IG-M3 ∙ M4 ∙ M5 ∙ M6 ∙ M8 ∙ M10 ∙ M12
849AG-M3 ∙ M4 ∙ M5 ∙ M6 ∙ M8 ∙ M10 ∙ M12
849IG-6.3 ∙ 8
849AG-6.3 ∙ 10
2100-025 ∙ 2250-1 ∙ 3

1 L x W x H è 4
mm
849 355 x 235 x 65 21 035984

849 IG COMPONENTS 2126 Thread restorer

Made in Germany bEG67 • Application: Restoring damaged outside or inside threads
• Surface: nickel-plated • Surface: nickel-plated
• DIN ISO 2936 • Pitches from 0.8 to 3.0 mm

1 K M N R 4

• Tap for inside thread
849 IG-M 3 – – – M 3 x 0.5 036127
849 IG-M 4 – – – M 4 x 0.7 036134 1 4
849 IG-M 5 – – – M 5 x 0.8 036141 K
849 IG-M 6 – – – M 6 x 1.0 036158 2126 230 012497
849 IG-M 8 – – – M 8 x 1.25 036165
849 IG-M 10 – – – M 10 x 1.5 036103
849 IG-M 12 – – – M 12 x 1.75 036110 847 Nut splitter ∙ mechanical
• Dies for male threads
849 AG-M 3 – – – M 3 x 0.5 036035 Made in Germany /
849 AG-M 4 – – – M 4 x 0.7 036042
849 AG-M 5 – – – M 5 x 0.8 036059
849 AG-M 6 – – – M 6 x 1.0 036066
849 AG-M 8 – – – M 8 x 1.25 036073
849 AG-M 10 – – – M 10 x 1.5 036011
849 AG-M 12 – – – M 12 x 1.75 036028
• Collet chuck
1
• g 6.3 = ⁄4″, for tap
849IG-M3 to M6
(together with connector 2250-1)
849 IG-6.3 – – – – 036080
• Collet chuck
• g 8 = ⁄16″, for tap
5
849IG-M8 to M12
(together with connector 2250-3)
849 IG-8 – – – – 036097
• Holder
• Outer x 32 mm
Inside x 25 mm
• j Drive 6.3 = /4″, for dies 849AG-M3 to M6 (25 mm x)
1
849 AG-6.3 64 – – – 036004
• Holder
• Outer x 32 mm 1 k 4
Inside x 25 mm
3
• j Drive 10 = /8″, for dies 849AG-M8 to M12 (25 mm x) For nuts M6 – M10
849 AG-10 68 – – – 035991 • Splitting tight nuts of the quality ranges 5 and 6
• Offset screwdriver 847-0410 A M6 – M10 139903
2100-025 – 58.5 20.5 – 011285 For nuts M10 – M16
1
1
• j 6.3 = ⁄4″ → b 6.3 = ⁄4″ • Splitting tight nuts of the quality ranges 5 and 6
2250-1 23.5 – – – 015443 847-1027 A M10 – M16 139910
• j 10 = ⁄8″ → b 8 = ⁄16″ • Spare chisel for mechanical ∙ HAZET nut splitters 847-0410A and 1027A
3
5
2250-3 31 – – – 015474 847-10 A – 144150
