Hand tools Hand tools

Internal extractor Internal extractor

Internal extractor

1788 N Internal extractor 1788 N Internal extractor set

Made in Germany C

• Application: Extracting ball bearings, outer rings and bushings 1 è 4
• To be used with counter stays 1788N-835 and 1788N-4570
1788 N
1788 N-835 • 1788 N-4570 • 1788 N-15 • 1788 N-19
1788 N-25 • 1788 N-30 • 1788 N-35 • 1788 N-45
1788 N/8 8 133185
1788 N
1788 N-835 • 1788 N-4570 • 1788 N-15 • 1788 N-19 • 1788 N-25
1788 N-30 • 1788 N-35 • 1788 N-45 • 1788 N-55 • 1788 N-70
1788 N/10 10 147939

1788 T Internal extractor set
1) Reinforced bond – easy and safe extraction of needle
bearings, ball bearings and brass sleeves Made in Germany
1 t R 4 • Titanium-nitrided surface extra hard and wear-resistant ®

1788 N-12 1) 12 – 14 M 10 147694 • For tightly-packed ball bearings, rings, bushings and shaft seals Simmer
• Flexible material
1788 N-14 1) 14 – 19 M 10 147700 • Absolutely precise manufacturing accuracy providing a higher power transfer
1788 N-15 12 – 15 M 10 134861 • High ease of use
1788 N-19 15 – 19 M 10 134878 • Only 4 Internal Extractors allow to cover the range from 5 to 36 mm
1788 N-25 19 – 25 M 10 134885 • To be used sliding hammer or counter stay
1788 N-30 25 – 30 M 10 134892 • Well-composed set
1788 N-35 30 – 35 M 10 134915 • Hard and wear-resistant titanium nitrided surfaces providing
1788 N-45 35 – 45 M 14 x 1.5 134502 a better and heat-resistant surface protection
1788 N-55 45 – 55 M 14 x 1.5 136209 • Application:
1788 N-70 55 – 70 M 14 x 1.5 136216 • Insert internal extractor into bearing and screw in spindle
• The sharp shells press behind the
part to be removed
1788 N Counter stay • Place sliding hammer or
counter stay in position
Made in Germany • Plastic box
• For internal extractors HAZET 1788N-12 to 1788N-70
• Surface: chrome-plated

1 R K è 4

1 Spindle 4 • Internal extractor set, contents:
1788T-1 ∙ 1788T-8.5
1788T-15 ∙ 24 ∙ 36
• For internal extractors 1788N-12 up to 35 1788 T/5 – – 5 133666
1788 N- 835 M 10 mm 134854
• For internal extractors 1788N-45 up to 55 • Impact extractor (sliding hammer – sliding weight
200 g) with coupler thread M10
1788 N-4570 M 14 x 1.5 mm 134908 • Removal of caps with inside thread, ball bearings, washers etc.
• To be used with stud bolt set 1788T-1/6 and internal extractors 1788N-15 to 35
1788 N Internal extractor set • Also together with injector extractor 4797-5 – 134304
226
M 10
1788 T-1
Made in Germany
• Extracting ball bearings, outer rings and bushings 1788 T Stud bolt set
• Internal extractor and counter stay Made in Germany
• Sheet metal box (HAZET blue)
• Application: Removing different caps with inside thread
• 6-piece set, ∙ stud bolts with M10 coupler thread, contents:
1 piece each threaded insert M4, M5, M6, M8, M10, M12
Use with sliding hammer 1788T-1

1 è 4
B 1788 T-1/6 6 141647
258 Errors excepted Components and spare parts from page 500 to 509
