Hand tools

Internal extractor

1788 T Impact extractor 1774 Beam puller

Made in Germany Made in Germany
• Application: For disassembly of tight common rail • Drop forged, tempered hooks
injectors without removing the cylinder head
• Application: Tensioning,
pulling, pressing of timbers
• Beam puller
• Galvanized hooks,
chrome-plated ratchet
• Ergonomic design – with
reversible ratchet
• Smooth running acme
1 R K 4 thread TR 16 x 5
• Span: 115 mm
• Impact extractor (sliding hammer – sliding weight Total width: 440 mm
200 g) with coupler thread M10 Length of ratchet: 275 mm
• Removal of caps with inside thread, ball bearings, washers etc.
• To be used with stud bolt set 1788T-1/6 and internal extractors 1788N-15 to 35
• Also together with injector extractor 4797-5
1788 T-1 M 10 226 134304
Easy removal of injectors together with impact extractor e.g. HAZET 1788 T-1
• Injector claw with inside thread M10 x 1.5 mm
• MAN Engines D08 ∙ D20 ∙ D26 ∙ D28
• Suited to the very limited space conditions in the cylinder head
• Due to the tool‘s claw, the injector in the upper part 1 4
may be gripped without causing damage
4797-5 – 174 176137 1774-1 180578
1778 Ball bearing extractor set

Made in Germany
• Considerably easier application than existing systems on the market
providing more efficiency and productivity

• Application: Removal of ball bearings mounted on shafts and located in housings
• For more than 40 standard ball bearings up to size 6311
• User-friendly device prevents the puller hooks from falling off
• 100% power transmission due to self-gripping closure
• 40-piece set
For ball bearing 6000 to 6407

Bearing Hook Receptacle Bearing Hook Receptacle
6000 1778-10 1778-3 6011 1778-50 1778-4
6001 1778-10 1778-2 6012 1778-50 1778-4
6002 1778-10 1778-1 6206 1778-50 1778-4
6003 1778-10 1778-2 6207 1778-50 1778-4
6004 1778-30 1778-1 6208 1778-60 1778-4
6005 1778-30 1778-1 6209 1778-60 1778-4
6006 1778-30 1778-1 6210 1778-60 1778-4
6007 1778-40 1778-1 6211 1778-60 1778-4
6008 1778-40 1778-1 6212 1778-70 1778-4
6009 1778-40 1778-1 6213 1778-70 1778-6
6010 1778-40 1778-1 6305 1778-60 1778-6
6200 1778-10 1778-2 6306 1778-60 1778-5
6201 1778-20 1778-3 6307 1778-60 1778-5
6202 1778-20 1778-2 6308 1778-70 1778-5
6203 1778-30 1778-2 6309 1778-70 1778-5
6204 1778-40 1778-2 6310 1778-70 1778-5 + 1778-8
6205 1778-40 1778-1 6311 1778-70 1778-5 + 1778-9
6300 1778-30 1778-1 6403 1778-60 1778-4
6301 1778-40 1778-1 6404 1778-70 1778-4
6302 1778-40 1778-3 6405 1778-70 1778-6
6303 1778-40 1778-3 6406 1778-70 1778-6
6304 1778-40 1778-3 6407 1778-60 1778-6 + 1778-7
Note: this table serves as an orientation aid when selecting the extractor
parts and does not claim to be correct and/or complete

1 è 4
1778-3/40 40 133697

Ball joint puller tools can be found under
Specialty Tools → Chassis → Wheel Bearing / Wheel Hub from page 458
