Page 262 - HAZET哈蔡特2024英文样本

Hand tools Hand tools

Grinding, separation and cutting Grinding, separation and cutting

Grinding, separation and cutting

2128 Twist drill bits in case 2150 Marking tool

• Save time and energy: The HSS twist drills enable rapid drilling with less • Surface: burnished, oiled A
contact force than conventional drills
• Powerful, precision-ground twist drills made of high performance HS steel (HSS)
• Self-centring drill bit with taper surface grinding according to DIN 1412 ∙
118° point angle ∙ perfect centring without centre punch or wandering
• Two cutting edges and two spiral grooves remove
the chip quickly and extend the use life
• Long use life (service life), excellent wear resistance thanks to robust core
thickness and emphasised hardness (surface finish) for the working area 1
• Cylindrical shaft (shaft diameter corresponds to drill diameter) ∙ Diameter K 4
tolerance h 8 ∙ Highest precision (increased concentric accuracy) 2150 240 013012
• 25-piece, x 1 – 13 mm increasing by 0.5 mm: 1 drill each x x 1.0 ∙ 1.5 ∙ 2.0 ∙ 2.5 ∙
3.0 ∙ 3.5 ∙ 4.0 ∙ 4.5 ∙ 5.0 ∙ 5.5 ∙ 6.0 ∙ 6.5 ∙ 7.0 ∙ 7.5 ∙ 8.0 ∙ 8.5 ∙ 9.0 ∙ 9.5 ∙ 10.0 ∙
10.5 ∙ 11.0 ∙ 11.5 ∙ 12.0 ∙ 12.5 ∙ 13.0 mm • Special steel for long-lasting use
• Right hand cutting • With fastening clip A
• DIN 338

1 K 4
2150-1 150 144129

2119 Half-round file

Made in Germany
• Teeth (cut): 2 = medium
• Plastic handle
• DIN 7261 form E
1 4
2128 N-1 218844

1967 Welding spot drill
Made in Germany A
• Self-cutting centring tip
resharpenable
• High performance, high-speed steel, blued

1 K 4
1 K t 4 2119- 8 200 012398

1967-70 74 7 009343 2119-10 250 012381
1967-80 79 8 009350
1967-90 79 9 009367 2120 Round file

1967 Welding spot drill Made in Germany
• Teeth (cut): 2 = medium
• DIN 7261 form F
Made in Germany A/
• Suitable for drills
• 7 mm hexagon shank
prevents slippage in drill chuck
• Replaceable cutting
crown (right-hand thread)
made of high-speed steel (oiled)
• Cutting crown for use at both ends
• With screw for gauge depth adjustment (*)

1 K t 4
1967 70 11 009312
Spare cutting crowns, set of 5, for 1967
1967-01/5 – – 211319 1 K 4
• Tip for HAZET welding spot drill 1967 2120- 8 200 012411
1967-02 – – 009336 2120-10 250 012404
260 Errors excepted Components and spare parts from page 500 to 509
