P. 238

Hand tools                                                                                                     Hand tools

                                                             Pliers                                                                                                         Pliers


        1845 D Circlip pliers                                 1845 Circlip pliers set

           Made in Germany                                       Made in Germany
            •  Safe and fast working                              •  Safe and fast working
        •  Firm hold on the safety ring thanks to precise, conical   •  Firm hold on the safety ring thanks to precise, conical
         and relief-ground jaws (phosphatized)                 and relief-ground jaws (phosphatized)
        •  Solid plastic body                                 •  Solid plastic body
            – Extremely resilient metal core extends far into the pliers‘ shanks    – Extremely resilient metal core extends far into the pliers‘ shanks
            – Light-weight – ergonomically shaped                – Light-weight – ergonomically shaped
        •  Readjusting spring                                 •  Readjusting spring
        •  Twist-safe, tips are welded to the solid metal core  •  Twist-safe, tips
        •  Tips bent 90° (form D)                              are welded to the
        •  For inside lockrings                                solid metal core
                                                              •  DIN 5254, DIN 5256
















                                                              1845 A-19    1845 B-19
        1            K        L        =       4                                        1845 C-19    1845 D-19
        1845 D-  8  133      8 – 11    0.9     048755
        1845 D-12   133      12 – 25   1.3     048762         1                   è                  4
        1845 D-19   170      19 – 60   1.8     048779         1845/4               4                 184132

        1845 Circlip pliers set                                  Made in Germany                            S/
                                                                  •  Safety-Insert-System, 2-component soft foam insert.
           Made in Germany                                     Insert also suitable for HAZET Assistent
            •  Safe and fast working                          •  DIN 5254
        •  Firm hold on the safety ring thanks to precise, conical
         and relief-ground jaws (phosphatized)
        •  Solid plastic body
            – Extremely resilient metal core extends far into the pliers‘ shanks
            – Light-weight – ergonomically shaped
        •  Readjusting spring
        •  Twist-safe, tips are welded to the solid metal core
        •  DIN 5254

                                                              1845 A-19    1845 B-19
                                                                                        1845 C-19    1845 D-19

                                                              1              L x W        è          4
                                                                              mm
                                                              163-124/4     342 x 172      4         153602

                                                              1846 A Circlip pliers

                                                                 Made in Germany
                                                                  •  Cylindrical tips worked out in optimal angle
                                                              •  Exactly defined, extra stable cone tips
                                                              •  Safe fit of the lockring
                                                              •  Electrothermic hardening and tempering
                                                              •  Straight design (from C)
                                                              •  For inside lockrings
                                                              •  Surface: chrome-plated, tip steel grey
                                                              •  DIN 5256 form C
        1845 A
        1845 A-10 • 1845 A-19  1845 C      1845 D
                         1845 C-8 • 1845 C-19  1845 D-8 • 1845 D-19

        1845 B                                                1           K         L        =       4
        1845 B-10 • 1845 B-19                                 1846 A-0    139      8 – 13    0.9     006793
                                                              1846 A-1    140     12 – 25    1.3     006809
        1                   è                  4              1846 A-2    180     40 – 100   1.8     006816
                                                                                  19 – 60
                                                                                                     006823
                                                                                             2.3
                                                                          225
                                                              1846 A-3
        1845/8               8                 048656         1846 A-4    310     85 – 140   3.2     006830
        236     Errors excepted                                              Components and spare parts from page 500 to 509
