Hand tools

Pliers
Pictogram key

n For flat material on pliers 7 Flat nose pliers
u For round material on pliers 8 Snipe nose pliers
4 Centre cutter w Inside lockrings

5 Flush cutter y Outside lockrings
6 Round-nose pliers

Small HAZET pliers basics

Joint types

Lay-on slip joint: Lap joint: Box joint:
Here the two halves of the Here each shank of the pliers is Here one half of the pliers shank is slotted
pliers sit on top of each other wrought as far as half way inside the so that the other half can be pushed
without special elaboration. joint area in such a way that both through with an exact fit. Advantage:
shanks sit optimally inside each other with the two-sided mounting of the
joint bolt and the double guidance
of the pliers‘ inside shank, this joint
connection can withhold high loads.

Jaw forms

Flat Snipe nose Obtusely curved

Gripping area

• Chequered in accordance with DIN ISO 5742
