Page 230 - HAZET哈蔡特2024英文样本

Hand tools

Screwdrivers / Bits

2218 Bit 2272 Impact bit screwdriver

Made in Germany MH • Impact operation of tight screw connections G
5
• Hexagon drive similar to ISO 1173 C8 ( ⁄16″) • Up to 80 Nm loosening and tightening torque
• Switchable (right- and left-hand threads)
• Pretension impact screwdriver by rotating the handle left (loosening or right-
hand thread) or right (tightening or left-hand thread) before every impact.
Hit the head section of the impact screwdriver with a 300 g hammer
1) Reinforced design • No electricity, compressed air or other resources needed
1 K 4
2218-PZ 1 32 014705
2218-PZ 2 32 014712
2218-PZ 3 32 014729
2218-PZ 4 1) 38 014736

2224 Bit
1 4
Made in Germany NH K
5
• Hexagon drive ISO 1173 C8 ( ⁄16″) 2272 165 015979
8808 S 5/16″→3/8″ Impact adapter

1 K r 4
Made in Germany
2224-T 25 35 4.43 015115 • Fixation of impact sockets with j drive 10 = /8″ 2H
3
2224-T 27 35 4.99 015122 • With locking pin retaining
2224-T 30 35 5.52 015139 • Surface: steel grey, oiled
2224-T 40 35 6.65 015160
2224-T 45 35 7.82 015177
2224-T 50 35 8.83 015184
2224-T 55 35 11.22 015191

2224 SLG Bit

Made in Germany NH 1 K 4
• Long design • Adapter g 8 = ⁄16″ → i 10 = ⁄8″
5
3
• Hexagon drive
ISO 1173 C8 ( ⁄16″) 8808 S-1 75 040032
5

1 K r 4 2250 Adapter
2224 S Lg-T 30 100 5.52 015245 Made in Germany G78
2224 S Lg-T 40 100 6.65 015252 • Inside square and inside hexagon sockets
2224 S Lg-T 45 100 7.82 015269 • With locking spring to securely hold the bits
2224 S Lg-T 50 100 8.83 015283 • Surface: chrome-plated
2206 Bit

Made in Germany bH
5
• Hexagon drive ISO 1173 C8 ( ⁄16″),
ISO 2351-3 C8 1 K 4
• j 10 = ⁄8″ → b 8 = ⁄16″
3
5
2250-3 31 015474
1) Not according to ISO 2351-3 1 5
1 S K 4 • j 12.5 = ⁄2″ → b 8 = ⁄16″ 36 015511
2250-5
2206-5 5 30 014262
2206-6 6 30 014279
2206-7 7 30 151349
2206-8 8 30 014286
2206-10 1) 10 30 014255
2212 Bit
Made in Germany PH
5
• DIN 65254, Hexagon drive ISO 1173 C8 ( ⁄16″)

1 K 4
2212- 6 32 056415
2212- 8 32 056422
2212-10 32 056439
228 Errors excepted Components and spare parts from page 500 to 509
