Hand tools Hand tools

Screwdrivers / Bits Screwdrivers / Bits

2204 NELG Bit 863-Bit 1/4″ Reversible ratchet for

• Extra long design bF screwdriver bits ∙ fine-tooth
1
• Hexagon drive ISO 1173 C6.3 ( ⁄4″), ISO 2351-3 C6,3 C
E /

1 S K 4
2204 N E Lg-3 3 89 243990
2204 N E Lg-4 4 89 244003
2204 N E Lg-5 5 89 244010
2204 N E Lg-6 6 89 244027
1 K 4
2211 Bit 863 HP B 116 235346

Made in Germany PF 1/4″ Reversible ratchet ∙
• DIN 65254, Hexagon drive ISO 1173 C6.3 ( ⁄4″) 863-Bit
1
solid steel ∙ for bits
Made in Germany E
• 90 mm short design

1 K 4 • Number of teeth: 60
(Opening angle 6°)
2211-4 25 056392 • With locking spring to
2211-5 25 056408 securely hold the bits
• Surface: chrome-plated
2225 5-star bit

Made in Germany UF
• Operation of inside 5-star screws with pin 1 K 4
• Hexagon drive ISO 1173 C6.3 ( ⁄4″)
1
863 MB 90 212187
Wear? – No problem!
1 K 4
2225-10 H 25 097043 • HAZET tools are manufactured to the highest
quality. During long intensive loading there is a
2225-15 H 25 097050 certain level of wear even for high-quality tools.
2225-20 H 25 097067 • For this reason, there are spare parts and
2225-25 H 25 097074 replacement sets available for many of our tools.
2225-27 H 25 097081
2225-30 H 25 097098
2225-40 H 25 097104 Please also see our spare parts shop
www.hazet.de/ersatzteil-shop
1/4″ Reversible ratchet for Cost-saving – Sustainable – Resource-saving!
863-Bit For long-term pleasure with your HAZET tools
screwdriver bits ∙ fine-tooth
Made in Germany E /
• A lot more power than with ratchets with the same dimensions
863 Replacement set
• Latching function of the shift lever provides protection against unwanted switching
• Increased service life thanks to the use of state-of- Made in Germany
the-art lubricants in the ratchet mechanism
• Strict production tolerances prevent dirt from getting in
• HAZET internal quality standards guarantee loading
capacity far beyond the standard requirements
• Chrome-plated surface: High-quality, easy to clean, corrosion resistant
• Integrated suspension option in the handle
• VPA tested, static torque according to DIN 3122: 120 Nm (DIN: 62 Nm)
• Number of teeth: 90 (Opening angle 4°)
• With locking spring to securely hold the bits 1 4
• HAZET 2-component handle
• Surface: chrome-plated • Replacement set for shift lever consisting of:
shift lever ∙ pawl ∙ screws ∙ ball ∙ compression spring
For HAZET reversible ratchet 863K ∙ 863 ∙ 863G ∙ 863P ∙ 863PC ∙ 863Q ∙
863S ∙ 863ST ∙ 863BGL ∙ 863BKC ∙ 863BK ∙ 863MC ∙ 863Mbit ∙ 2264
863 P/6 144600
1
• Replacement set for bit ratchet wheel h 6.3 = ⁄4” consisting of:
assembly tool ∙ cover plate ∙ bit ratchet wheel ∙ circlip ∙ cover disc ∙ shift lever ∙
spring sleeve ∙ ball ∙ compression spring ∙ pawl ∙ grease
For reversible ratchet 863HPB
863 HP B/11 241279
1
• Replacement set for ratchet wheel h 6.3 = ⁄4″ consisting of:
ratchet wheel ∙ pawl ∙ shift lever ∙ screws ∙ ball ∙ compression spring
For HAZET reversible ratchet 863BGL ∙ 863BKC ∙ 863BK ∙ 863MBit ∙ 2264
B 2264/7 015917
224 Errors excepted Components and spare parts from page 500 to 509
