Hand tools

3 Range of sockets

900 SR SmartRail ∙ Flexible plastic plug-in rail 916 1/2″ Reversible ratchet
Made in Germany 3 /
Made in Germany 8 • Number of teeth: 32 (Opening angle 11.25°)
• Magnetic underside ensures grip on all ferrous surfaces, • With locking ball
e.g. on tool trolleys, tool walls, machines, lifting platforms • HAZET 2-component handle
and in metal drawers • Surface: chrome-plated, polished
• DIN 3122, ISO 3315
• HAZET SmartRail – Developed and produced „Made in Germany“
• Easy to clean
• Durable, robust twist lock for a tight fit and instant access
• More securely fixed when locked: turn socket left to remove
• Robust metal lug for hanging
1
• With ⁄2″ square sockets

1 K 4
916 SP 275 046317
1 ⁄2
1/2″ Reversible ratchet ∙
916
long ∙ with hinge joint
Made in Germany 3 /
• Ratchet head can be swivelled > 180°
• Long design
1 L x W x H K 4 • Number of teeth: 32 (Opening angle 11.25°)
mm
• With hinge – for working in areas with restricted
• Empty, with 5x ⁄2” square sockets access and for getting around obstructive edges
1
900 SR-5 245 x 37.4 x 29.2 245 244508 • With locking ball
• Empty, with 8x ⁄2” square sockets • HAZET 2-component handle
1
• Surface: chrome-plated, polished
900 SR-8 365 x 37.4 x 29.2 365 244515 • DIN 3122, ISO 3315
916 1/2″ Reversible ratchet ∙ fine-tooth

Made in Germany 3 /
• A lot more power than with ratchets with the same dimensions
• Locking function of the lever prevents unwanted switching
• Increased service life thanks to the use of state-of-
the-art lubricants in the ratchet mechanism
• Strict production tolerances prevent dirt from getting in
• HAZET internal quality standards guarantee loading
capacity far beyond the standard requirements
• High-quality, easy to clean, corrosion-resistant
• Integrated suspension option in the handle 1 K 5 4
• VPA tested, static torque according to DIN 3122: 1000 Nm
• Number of teeth: 90 (Opening angle 4°) 916 GL 511 40 202485
• With locking ball
• HAZET 2-component handle 916 1/2″ Reversible ratchet ∙ short
• Surface: chrome-plated
• DIN 3122, ISO 3315
Made in Germany 3 /
• Only 199 mm short, in compact design of a 2 ratchet
• Maximum torque: 300 Nm
• Short design
• Number of teeth: 30 (Opening angle 12°)
• With locking ball
• HAZET 2-component handle
• Surface: chrome-plated, polished
• DIN 3122, ISO 3315

YouTube Clip

1 K 4 1 K 4
916 HP 275 213894 916 K 199 155736

Components and spare parts from page 500 to 509 Errors excepted 165
