Hand tools

3 Range of sockets

916 1/2″ Reversible ratchet ∙ fine-tooth ∙ short Wear? – No problem!

Made in Germany 3 • HAZET tools are manufactured to the highest
• A lot more power for ratchets with the same dimensions quality. During long intensive loading there is a
certain level of wear even for high-quality tools.
• Locking function of the lever prevents unwanted switching • For this reason, there are spare parts and
• Increased service life thanks to the use of state-of- replacement sets available for many of our tools.
the-art lubricants in the ratchet mechanism
• Strict production tolerances prevent dirt from getting in Please also see our spare parts shop
• HAZET internal quality standards guarantee loading www.hazet.de/ersatzteil-shop
capacity far beyond the standard requirements
• High-quality, easy to clean, corrosion-resistant Cost-saving – Sustainable – Resource-saving!
• Integrated suspension option in the handle For long-term pleasure with your HAZET tools
• VPA tested, static torque according to DIN 3122: 400 Nm
• Short design
• Number of teeth: 90 (Opening angle 4°)
• With locking ball
• HAZET 2-component handle 916 Replacement set
• Surface: chrome-plated
• Similar to DIN 3122, Similar to ISO 3315 1 ⁄2
Made in Germany

1 4
1
1 K 4 • Replacement set for ratchet wheel 12.5 = ⁄2″ i consisting of:
pawl ∙ compression spring ∙ ball ∙ spring sleeve ∙ shift lever ∙ cover disc ∙ circlip ∙
916 HP K 200 244379 ratchet wheel ∙ grease ∙ assembly tool
For reversible ratchets 916HP ∙ 916HPS ∙ 916HPL ∙ 916HPLg
916 HP/10 218981
1
916 1/2″ Reversible ratchet ∙ fine-tooth • Replacement set for ratchet wheel with safety lock 12 = ⁄2″ i
consisting of:
assembly tool ∙ ratchet wheel with safety lock ∙ circlip ∙ cover disc ∙ shift lever ∙
Made in Germany 3 / spring sleeve ∙ ball ∙ compression spring ∙ pawl ∙ grease
• A lot more power than with ratchets with the same dimensions For HAZET reversible ratchet 916HPS as well as for
retrofitting HAZET reversible ratchets 916HP ∙ 916HPL ∙
• Latching function of the shift lever provides protection against unwanted switching 916HPLg (reduction to maximum 850Nm peak load)
• Increased service life thanks to the use of state-of- 916 HP S/10 241255
the-art lubricants in the ratchet mechanism • Replacement set for ratchet wheel with safety lock 12.5 = ⁄2″ i
1
• Strict production tolerances prevent dirt from getting in consisting of:
• HAZET internal quality standards guarantee loading Shift lever ∙ 2 screws ∙ ball ∙ compression spring ∙ ratchet wheel
capacity far beyond the standard requirements with safety lock ∙ pawl
• High-quality, easy to clean, corrosion-resistant For HAZET reversible ratchet 916S as well as for retrofitting
• Integrated suspension option in the handle Hazet reversible ratchets 916SP ∙ 916GK ∙ 916L ∙ 916ST
• VPA tested, static torque according to DIN 3122: 850 Nm 916 S/7 046300
1
• Quick-release safety lock • Replacement set for shift lever 12.5 = ⁄2″ i consisting of:
• Sockets are securely locked in place shift lever ∙ 2 screws ∙ ball and compression spring and pawl
• Attached tools can easily be released by pressing the button with just one hand For HAZET reversible ratchet 916S ∙ 916SP ∙ 916GK ∙ 916LG ∙
916L ∙ 916GL ∙ 916ST and beam puller 1774-1
• Number of teeth: 90 (Opening angle 4°) 916 SP/6 144624
• With locking ball
1
• HAZET 2-component handle • Replacement set for ratchet wheel 12.5 = ⁄2″ i consisting of:
shift lever ∙ screws ∙ ball ∙ compression spring ∙ ratchet wheel and pawl
• Surface: chrome-plated For HAZET reversible ratchet 916SP ∙ 916GK ∙ 916Lg ∙
• DIN 3122, ISO 3315 916L ∙ 916GL ∙ 916ST
916 SP/7-1 046348
• Replacement set for ratchet wheel 12.5 = ⁄2″ i consisting of:
1
shift lever ∙ screws ∙ ball ∙ ratchet wheel and pawl
For HAZET reversible ratchet 916K
916 K/7 155743
914 1/2″ Flexible handle
YouTube Clip Made in Germany 3 /
• With hinge – for working in areas with restricted
access and for getting around obstructive edges
• With locking ball
• HAZET 2-component handle
• Surface: chrome-plated
• DIN 3122, ISO 3315
1) Length not according to DIN
1 K 4
1 K 4 914-15 396 046027
916 HP S 275 237258 914-18 1) 472 046041

Components and spare parts from page 500 to 509 Errors excepted 167
