Hand tools

3 Range of sockets

900 Z 1/2″ Socket ∙ 12-point 900 AZ 1/2″ Socket ∙ 12-point

Made in Germany % 8 Made in Germany % 8
• With knurling • American dimensions
• Surface: chrome-plated, polished • With knurling
• DIN 3124, ISO 2725-1 • Surface: chrome-plated, polished

1) Not according to DIN 1
1 K G H c 4 1 K G H c 4 ⁄2

900 Z- 8 38 12 22 7.5 045686 900 AZ-3/8 38 14.5 22 10.5 043699
900 Z- 9 1) 38 13.5 22 8.5 045693 900 AZ-7/16 38 16.4 22 10.5 043729
900 Z-10 38 14.9 22 10.5 045457 900 AZ-1/2 38 18.3 22 11 043620
900 Z-11 38 16.4 22 10.5 045464 900 AZ-9/16 38 20.5 22.5 11.5 043743
900 Z-12 38 17.5 22 11 045471 900 AZ-19/32 38 21.5 23.2 11.5 043668
900 Z-13 38 18.8 22 11 045488 900 AZ-5/8 38 22.7 23.6 12.5 043712
900 Z-14 38 20.3 22.5 11.5 045495 900 AZ-11/16 38 24.6 22 12.5 043637
900 Z-15 38 21.5 23.2 11.5 045501 900 AZ-3/4 38 26.8 23 14 043682
900 Z-16 38 22.7 23.6 12.5 045518 900 AZ-25/32 38 27.8 24 14 043675
900 Z-17 38 24.1 22 12.5 045525 900 AZ-13/16 38 28.6 25 14 043644
900 Z-18 38 25.4 22.4 14 045532 900 AZ-7/8 41.5 30.4 26 17.5 043736
900 Z-19 38 26.6 23 14 045549 900 AZ-15/16 44 32.6 26 20 043651
900 Z-20 38 27.8 24 14 045556 900 AZ-31/32 44 33.4 24.6 20 043705
900 Z-21 38 29 25 14 045563 900 AZ-1 44 34.6 24.8 20 043576
900 Z-22 41.5 30.4 25 17.5 045570 900 AZ-1.1/16 46 36.3 25 21 043583
900 Z-23 1) 41.5 31.4 26 17.5 045587 900 AZ-1.1/8 47 38.2 26.5 22 043606
900 Z-24 44 32.6 26 20 045594 900 AZ-1.3/16 50 40.1 28 25 043613
900 Z-25 1) 44 33.9 26.5 20 045600 900 AZ-1.1/4 50 42.3 28 24 043590
900 Z-26 1) 44 35.1 24 20 045617
900 Z-27 46 36.2 25 21 045624
900 Z-28 1) 47 37.5 26 22 045631
900 Z-30 50 40.1 28 25 045655 900 TZ 1/2″ Socket ∙ 12-point
900 Z-32 1) 50 42.3 28 24 045662
900 Z-33 1) 50 43.6 28 24 045679 Made in Germany
900 Z-34 1) 52 46 28 23.3 144792 % 8 I
900 Z-36 1) 57 49 28 25.6 192502 • Long design
• With knurling
• Surface: chrome-plated, polished
900 Z SmartRail ∙ Flexible plastic plug-in rail • DIN 3124, ISO 2725-1

Made in Germany % 8 /
• Magnetic underside ensures grip on all ferrous surfaces,
e.g. on tool trolleys, tool walls, machines, lifting platforms and in
metal drawers
• HAZET SmartRail – Developed and produced „Made in Germany“
• Easy to clean
• Durable, robust twist lock for a tight fit and instant access
• More securely fixed when locked: turn socket left to remove
• Robust metal lug for hanging
• With ⁄2″ square sockets
1
1) With rubber ply for spark plugs / not according to DIN
1 K G H c 4
900 TZ-10 85 14.9 22 10 053452
900 TZ-11 85 16.4 22 11.5 053445
900 TZ-12 85 17.5 22 12.3 045242
900 TZ-13 85 18.8 22 13.3 045259
900 TZ-14 85 19.9 22.5 15.2 045266
900 TZ-15 85 21.5 23.2 15.2 045273
900 TZ-16 85 22.7 23.6 16 045280
900 TZ-17 85 24.1 23.6 19 045297
900 TZ-18 85 24.6 23.6 19 045310
900 TZ-19 85 26.8 26 19 045334
900 TZ-20.8-13/16 1) 85 28.5 24.5 19 045341
1 K è 4 900 TZ-21 85 28.6 24.5 19 045358
900 TZ-22 85 30.4 25 22 045365
900 Z • % • 8 900 TZ-24 85 32.6 27.5 25 045389
10 • 13 • 17 • 19 • 22 900 TZ-27 85 36.3 30 28 045419
900 Z-SR/5 245 5 245291 900 TZ-30 85 40.1 33 31 045426

Components and spare parts from page 500 to 509 Errors excepted 169
