Hand tools

2 Range of sockets

8801 KK 3/8″ Screwdriver socket 8808 3/8″ Screwdriver socket

Made in Germany l b7 Made in Germany l P7
• Long design • Short design
• With ball-head • With knurling
• With knurling • Surface: TIN coated
• Surface: TIN coated • DIN 2324, DIN 2325

1 Ä M N F 4
1 S M N F 4 8808- 5 M5 13.5 40 19 039982
8801 KK- 5 5 89.5 116 17 039586 8808- 6 M6 13.5 40 19 039999
41
14.5
8808- 8
19
M8
040001
8801 KK- 6 6 89.5 116 17 039593 8808-10 M10 14.5 42 19 039975
8801 KK- 7 7 89.5 116 19 039609 3
8801 KK- 8 8 89.5 116 19 039616 ⁄8
8801 KK-10 10 88.5 116 19 039579 2250 Adapter
Made in Germany EG7
8802 3/8″ Screwdriver socket ∙ h • Inside square and inside hexagon sockets
• With locking spring to securely hold the bits
• Surface: chrome-plated
Made in Germany l N7
• Short design
• With knurling
• Surface: TIN coated

1 K 4

1 Ä M N F r 4 • j 10 = ⁄8″ → b 6.3 = ⁄4″ 30 015450
3
1
2250-2
8802-T 15 T15 17 43.5 19 3.27 039647 • j 10 = ⁄8″ → b 8 = ⁄16″
3
5
8802-T 20 T20 17 43.5 19 3.86 039654 2250-3 31 015474
8802-T 25 T25 17 43.5 19 4.43 039661
8802-T 27 T27 17 43.5 19 4.99 039678
8802-T 30 T30 17 43.5 19 5.52 039685
8802-T 40 T40 17 43.5 19 6.65 039708 8808 LG 3/8″ Screwdriver socket
8802-T 45 T45 17 43.5 19 7.82 039722
8802-T 50 T50 17 44.5 19 8.83 039753
Made in Germany l P7
• Long design
• With knurling
8803 3/8″ Screwdriver socket • Surface: TIN coated
• DIN 2324, DIN 2325
Made in Germany l K7
• Medium length design
• With knurling
• Surface:
TIN coated
• DIN ISO 2380-1

1 Ä M N F 4
8808 LG- 6 M6 62.3 89 19 204946
1 M N F 4 8808 LG- 8 M8 61.5 88 19 040025
8803-1 x 5.5 48.5 75 17 039814 8808 LG-10 M10 61.5 89 19 040018
8803-1.2 x 8 53.5 80 19 039791
8803-1.6 x 10 62.5 90 19 039807 8858 Adapter
Made in Germany
8806 3/8″ Screwdriver socket • With locking ball 317
• Surface: chrome-plated
• DIN 3123, ISO 3316
Made in Germany l L7
• Short design
• With knurling
• Surface: TIN coated
• Tip ISO 8764-1

1 4
1 Ä M N F 4 K
1
3
8806-PH 1 PH1 23.5 50 17 039845 • Amplifier j input 10 = /8″ → i output 12.5 = /2″
8806-PH 2 PH2 23.5 50 17 039852 8858-1 36 042562
1
3
8806-PH 3 PH3 28.5 55 19 039869 • Reducer j input 10 = /8″ → i output 6.3 = /4″
8806-PH 4 PH4 32.5 60 19 039876 8858-2 26 042579
Components and spare parts from page 500 to 509 Errors excepted 161
