L
d1 d2

A [mm] d [mm] d1 [mm] d2 [mm] d2 [mm] L [mm] [g]
97.6X7 6x7 4,0 9,5 10,7 10,7 110 35
97.8X9 8x9 4,0 12,5 14,0 14,0 120 50
97.10X11 10x11 6,0 15,0 16,0 16,0 130 65
A [mm] 包装 [kg] 97.12X13 12x13 6,0 17,5 19,0 19,0 140 110
97.14X15 14x15 6,5 20,0 21,5 21,5 150 140
76.JN8 8 - 10 - 11 - 13 - 17 - 19 - 22 - 24 纸盒 2,370 97.16X17 16x17 8,2 22,7 24,0 24,0 160 190
97.18X19 18x19 8,2 25,2 26,5 26,5 170 240
76.JN10 8 - 10 - 11 - 12 - 13 - 14 - 16 - 17 - 18 - 19 纸盒 2,160 97.20X22 20x22 10,2 27,7 30,2 30,2 180 260
8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 97.21X23 21x23 10,2 29,0 31,2 31,2 185 295
76.JE16 纸盒 4,700
21 - 22 - 23 - 24 97.24X26 24x26 12,5 33,0 35,5 35,5 190 415
8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 97.27X29 27x29 12,5 37,0 39,5 39,5 200 505
76.P22M 21 - 22 - 23 - 24 - 26 - 27 - 28 - 29 - 30 - 32 挂板: PK.1 13,340 97.30X32 30x32 12,5 40,5 43,0 43,0 200 630

L

L1
H
B A [mm] 包装 [kg]
97.JE6 8x9 - 10x11 - 12x13 - 14x15 - 16x17 -18x19 纸盒 0,770

A [mm] B [mm] H [mm] L [mm] L1 [mm] [g]
92A.4 4 8,5 16,5 95 23,5 20
92A.5 5 9,5 16,0 95 23,5 20
92A.5.5 5,5 10,0 17,5 95 25,0 25
92A.6 6 10,5 17,5 100 26,5 30
92A.7 7 11,5 19,5 100 28,5 30
92A.8 8 13,0 20,5 109 31,5 45
92A.9 9 14,5 22,0 109 33,0 50
92A.10 10 16,0 23,0 118 36,5 65
92A.11 11 17,0 23,0 118 36,5 70
92A.12 12 19,0 27,0 127 43,0 100
92A.13 13 20,5 27,0 127 43,0 110
92A.14 14 21,5 31,0 136 49,0 155
92A.15 15 22,5 31,0 136 49,0 160
92A.16 16 24,0 35,0 145 55,0 190
92A.17 17 26,0 35,0 145 55,0 200
92A.18 18 27,5 39,0 154 61,0 225
92A.19 19 28,5 39,0 154 61,0 230
92A.20 20 29,5 41,5 163 66,5 320
92A.21 21 31,0 42,5 163 67,5 325
92A.22 22 32,0 42,5 172 68,0 350
92A.24 24 34,5 45,5 175 74,5 415 A [mm] 包装 [g]
92A.30 30 42,5 53,5 195 86,5 640 MOD.97 8x9 - 10x11 - 12x13 - 14x15 - 16x17 - 18x19 托盘: PL.359 900
