902-497 Compartment Storage Box SB-2419 Storage Box
• Adjustable compartments for multiple uses • Tight seal between top and compartments prevents
small components from being mixed while closed.

Close Open

192
42
Sliding lock
238
Unit: inch
Dimension Individual
Material STORAGE/INSTRUMENT CASES
(mm/inch) packing Material Dimension Individual
packing
(mm/inch)
PP 35.8x23.5x6 / Shrink packing 238x192x42 Color label
1.4x0.9x0.2 Polypropylene 9.4x7.6x1.7 shrink
900-040 Utility Component Storage Box 900-041 Utility Component Storage Box

7.0
5.3
1.7
1.5
10.8 7.9
Unit: inch Unit: inch
Material Dimension (mm/inch) Individual packing Material Dimension (mm/inch) Individual packing
PP 275x177x42.5/10.8x7.0x1.7 Shrink packing PP 200x135x39/7.9x5.3x1.5 Shrink packing
900-039 Utility Component Storage Box 902-112 Utility Component Storage Box

4.5
1.3
1.7
4.7
10.2 8.3
Unit: inch Unit: inch
Material Dimension (mm/inch) Individual packing Material Dimension (mm/inch) Individual packing
PP 260x115x43.5/10.2x4.5x1.7 Shrink packing PP 210x119x32/8.3x4.7x1.3 Poly bag
902-113 Utility Component Storage Box 902-114 Utility Component Storage Box

2.4
0.83 0.87
4.6
7.4
3.0 Unit: inch Unit: inch
Material Dimension (mm/inch) Individual packing Material Dimension (mm/inch) Individual packing
PP 76x61x21/3.0x2.4x0.83 Shrink packing PP 187.5x117x22/7.4x4.6x0.87 Poly Bag
900-091A Parts Tubes 900-043 Utility Component Storage Box

PP PP
3.7
6.5
H: 1.8 Unit: inch

Material Dimension (mm/inch) Individual packing Material Dimension (mm/inch) Individual packing
PP Ø20x130/Ø0.79x5.1 Clamshell (3pcs/pack) PP/PE 165x95x45/6.5x3.7x1.8 Shrink packing
