SB-3428SB / SB-4536B Service Case

STORAGE/INSTRUMENT CASES Double sided

opening

SB-3428SB
• Double sided opening
• Adjustable dividers up to 15 compartments and
5 large and 5 small removable inserts in the other
Demo only side for storage flexibility. SB-4536B
Dimension (LxWxH)
Model No. Material (mm/inch) • 6 large and 6 small removable
340x280x80 Demo only inserts for storage flexibility
SB-3428SB polypropylene 13.6x11.0x3.1
+ W • Made from high impact resistant polypropylene and poly styrene, sturdy
450x355x75
SB-4536B polystyrene 17.7x14.0x3.0 H and durable
• Properly divided spaces reach the different needs of any small components.
Individual packing L • Integrated handle and two locks for convenient carrying.
Color label shrink Unit: inch • Easy to store, easy to find
900-164A/900-164B Instrument Cases
• The durable ABS plastic cases allow for various PCB mounting positions.
Adhesive feet and screws are included, choose from 2 sizes. 900-164B has ventilation slots and speaker recess.

H
900-164A 900-164B
L(mm/inch) W(mm/inch) H(mm/inch)
Model No. Material Individual packing
OD ID OD ID OD ID L
900-164A ABS 200/7.9 197/7.8 158/6.2 146/5.7 64/2.5 58/2.3 Poly bag W
900-164B 253/10.0 250/9.8 190/7.2 176/6.9 82/3.2 76/3.0 Demo only Unit: mm/inch
900-162A/900-162B/900-162C Die Cast Aluminum Enclosures
• The heavy-duty enclosures are made of high quality die-cast aluminum and have channeled walls for easy PCB mounting.
• These enclosures act as excellent heat sink.
• Easy assembly screws included.

900-162A 900-162B 900-162C
H

L(mm/inch) W(mm/inch) H(mm/inch) Individual
Model No. Material
OD ID OD ID OD ID packing L
900-162A 101/4.0 97/3.8 50.6/2.0 46.6/1.8 20.7/0.81 18.8/0.74 W Unit: mm/inch
Shrink
900-162B Aluminum 121/4.8 116.9/4.6 66.1/2.6 62/2.4 35.4/1.4 33.5/1.3 packing Width of inside grooves:
900-162C 193.5/7.6 187.5/7.4 112.4/4.4 106.5/4.2 56.2/2.2 54/2.1 Demo only 2.95mm/0.16"
