CUSTOM kITS ARe AVAILABLe. IdenTIFICATIOn InFORMATIOn

ILL 26

INTERCHANGEABLE PROBE REMOvAL KIT INTERCHANGEABLE PROBE INSERTION KIT

Common handle and 3 tips for sizes 12, 16 and Common handle and 3 tips for sizes 12, 16 and
20 gage contacts, with shedders for MIL-C-26482, 20 gage contacts for MIL-C-26482, 26500 and
26500 and 26636 connectors. 26636 connectors.

ILL 27 This long-slot tool illustrates the standard for MIL-C-005015
insertion tools. Modified versions are available on request.

PLASTIC TOOLS vs. ASTRO METAL TOOLS
Plastic tools are used throughout the industry. Astro Tool Corp’s policy is to
give our customers the greatest savings for the best quality tools we can
manufacture. Metal tools, although initially more costly, offer a quality
product and a lower tooling cost in servicing electrical connectors. Please BURndy’S yHMM TOOL
refer to our cross-reference lists for any plastic to metal replacement
equivalents you may need. ILL 29

The tools are available in two basic lengths
with a metal or plastic insertion foot.

ILL 28
COLLIn’S RAdIO FILTeR PIn
InSeRTIOn TOOL

ILL 30

87
