千分尺专用量块

平面平晶(标配)
量块尺寸:
H 长度(L) W H
0.5 ≤ L ≤10mm 9mm 30mm
L>10mm 9mm 35mm
L
W
应用

符合JJG量块国家计量检定规程, 0级/2等
配一个平面平晶(规格Ø30x12mm), 检查平面度
带生产厂检验证书
4160-10

型号 材质 每套包含的量块 适用的千分尺

2.5mm, 5.1mm, 7.7mm, 10.3mm, 12.9mm,
4160-10 钢 0-25mm
15mm, 17.6mm, 20.2mm, 22.8mm, 25mm

千分尺专用量块

量块尺寸:
长度(L) W H
H
0.5 ≤ L ≤10mm 9mm 30mm
L>10mm 9mm 35mm
L
W

符合JJG量块国家计量检定规程, 0级/2等
4107-10, 4107-101配一个平面平晶, 检查平面度
带生产厂检验证书
14 4107-10

型号 材质 每套包含的量块 适用的千分尺 平面平晶
2.5mm, 5.1mm, 7.7mm, 10.3mm, 12.9mm, 15mm, 17.6mm,
4107-10 陶瓷 0-25mm 标配
20.2mm, 22.8mm, 25mm
2.5mm, 5.1mm, 7.7mm, 10.3mm, 12.9mm, 15mm, 17.6mm,
4107-101 钢 0-25mm 标配
20.2mm, 22.8mm, 25mm
25mm, 27.5mm, 30.1mm, 32.7mm, 35.3mm, 37.9mm, 40mm,
4107-112 钢 25-50mm 不标配
42.6mm, 45.2mm, 47.8mm, 50mm
50mm, 52.5mm, 55.1mm, 57.7mm, 60.3mm, 62.9mm, 65mm,
4107-113 钢 50-75mm 不标配
67.6mm, 70.2mm, 72.8mm, 75mm
75mm, 77.5mm, 80.1mm, 82.7mm, 85.3mm, 87.9mm, 90mm,
4107-114 钢 75-100mm 不标配
92.6mm, 95.2mm, 97.8mm, 100mm
5.12mm, 10.24mm, 15.36mm, 21.5mm, 25mm, 30.12mm, 35.24mm,
4107-115 钢 40.36mm, 46.5mm, 50mm, 55.12mm, 60.24mm, 65.36mm, 71.5mm, 0-100mm 不标配
75mm, 80.12mm, 85.24mm, 90.36mm, 96.5mm, 100mm

543
