P. 551
定制量块 单支钢量块
可定制0.1~1000mm以内的任意⻓度, 如72.672mm
德国制造
符合JJG量块国家计量检定规程
可提供K级1等, 0级/2等和1级/3等量块
材质: 合金钢
以下规格带孔: 125, 150, 175, 200, 量块尺寸:
250, 300, 400, 500, 600, 700, 800, 长度(L) W H
900, 1000mm 4104-K70 4104-K200 0.5 ≤ L ≤10mm 9mm 30mm
带生产厂检验证书 L>10mm 9mm 35mm
单位: mm 型号说明: 型号举例:
L<125 L≥125 W
4104-X 长度(L) 级/等 型号
Ø10 0.5mm K/1 4104-KD5
H H K代 K级/1等
25 1mm 0/2 4104-A1
A代表0级/2等
10.5mm 1/3 4104-B10D5
不带孔 带孔 B代表1级/3等
长度(L) 型号 长度(L) 型号 长度(L) 型号 长度(L) 型号
0.1mm 4104-XD1 1.21mm 4104-X1D21 3mm 4104-X3 21mm 4104-X21
0.2mm 4104-XD2 1.22mm 4104-X1D22 3.5mm 4104-X3D5 21.5mm 4104-X21D5
0.3mm 4104-XD3 1.23mm 4104-X1D23 4mm 4104-X4 22mm 4104-X22
0.4mm 4104-XD4 1.24mm 4104-X1D24 4.5mm 4104-X4D5 22.5mm 4104-X22D5
0.5mm 4104-XD5 1.25mm 4104-X1D25 5mm 4104-X5 23mm 4104-X23
1mm 4104-X1 1.26mm 4104-X1D26 5.5mm 4104-X5D5 23.5mm 4104-X23D5
1.0005mm 4104-X1D0005 1.27mm 4104-X1D27 6mm 4104-X6 24mm 4104-X24
1.001mm 4104-X1D001 1.28mm 4104-X1D28 6.5mm 4104-X6D5 24.5mm 4104-X24D5
1.002mm 4104-X1D002 1.29mm 4104-X1D29 7mm 4104-X7 25mm 4104-X25
1.003mm 4104-X1D003 1.3mm 4104-X1D3 7.5mm 4104-X7D5 30mm 4104-X30
1.004mm 4104-X1D004 1.31mm 4104-X1D31 8mm 4104-X8 40mm 4104-X40
1.005mm 4104-X1D005 1.32mm 4104-X1D32 8.5mm 4104-X8D5 50mm 4104-X50
1.006mm 4104-X1D006 1.33mm 4104-X1D33 9mm 4104-X9 60mm 4104-X60
1.007mm 4104-X1D007 1.34mm 4104-X1D34 9.5mm 4104-X9D5 70mm 4104-X70
1.008mm 4104-X1D008 1.35mm 4104-X1D35 10mm 4104-X10 75mm 4104-X75
1.009mm 4104-X1D009 1.36mm 4104-X1D36 10.5mm 4104-X10D5 80mm 4104-X80
1.01mm 4104-X1D01 1.37mm 4104-X1D37 11mm 4104-X11 90mm 4104-X90
1.02mm 4104-X1D02 1.38mm 4104-X1D38 11.5mm 4104-X11D5 100mm 4104-X100
1.03mm 4104-X1D03 1.39mm 4104-X1D39 12mm 4104-X12 125mm 4104-X125 14
1.04mm 4104-X1D04 1.4mm 4104-X1D4 12.5mm 4104-X12D5 131.4mm 4104-X131D4
1.05mm 4104-X1D05 1.41mm 4104-X1D41 13mm 4104-X13 150mm 4104-X150
1.06mm 4104-X1D06 1.42mm 4104-X1D42 13.5mm 4104-X13D5 175mm 4104-X175
1.07mm 4104-X1D07 1.43mm 4104-X1D43 14mm 4104-X14 200mm 4104-X200
1.08mm 4104-X1D08 1.44mm 4104-X1D44 14.5mm 4104-X14D5 243.5mm 4104-X243D5
1.09mm 4104-X1D09 1.45mm 4104-X1D45 15mm 4104-X15 250mm 4104-X250
1.1mm 4104-X1D1 1.46mm 4104-X1D46 15.5mm 4104-X15D5 281.2mm 4104-X281D2
1.11mm 4104-X1D11 1.47mm 4104-X1D47 16mm 4104-X16 300mm 4104-X300
1.12mm 4104-X1D12 1.48mm 4104-X1D48 16.5mm 4104-X16D5 400mm 4104-X400
1.13mm 4104-X1D13 1.49mm 4104-X1D49 17mm 4104-X17 481.1mm 4104-X481D1
1.14mm 4104-X1D14 1.5mm 4104-X1D5 17.5mm 4104-X17D5 500mm 4104-X500
1.15mm 4104-X1D15 1.6mm 4104-X1D6 18mm 4104-X18 550mm 4104-X550
1.16mm 4104-X1D16 1.7mm 4104-X1D7 18.5mm 4104-X18D5 600mm 4104-X600
1.17mm 4104-X1D17 1.8mm 4104-X1D8 19mm 4104-X19 700mm 4104-X700
1.18mm 4104-X1D18 1.9mm 4104-X1D9 19.5mm 4104-X19D5 800mm 4104-X800
1.19mm 4104-X1D19 2mm 4104-X2 20mm 4104-X20 900mm 4104-X900
1.2mm 4104-X1D2 2.5mm 4104-X2D5 20.5mm 4104-X20D5 1000mm 4104-X1000
