280 2213/2BI
Torque multiplier Angle gauge

› this is used for screws on the heads of motors
where car manufacturers prescribe that, as
well as fastening the screws to the prescribed
torque, fastening at a certain angle is also
› 5:1 torque multiplication, accuracy guaranteed better than +/-4% required
› supplied with two reaction bar styles for maximum versatility › if your space is limited, you can also use an
› Robust construction means minimal maintenance and long life extension to obtain the required height
› Supplied in a carrying case. Ideal for inclusion in the heavy vehicle tool kit › the scale is 360°, divided into 2° angles

Advantages: How to use the tool:

› Exactly de"ned multiplication – no need of tabular conversions › hold the angle scale by its small handle to
› Simple use does not require any additional knowledge avoid rotation during screw joining, set the
indicator to zero and then fasten the screw at
Usage: the prescribed angle with another tool from the
› building construction 1/2" product range (e.g. a hinge handle which is
› agricultural equipment longer, because the forces are considerable)
› heavy industry
› larger construction machinery
› shipbuilding industry
› aircraft industry
› train compositions

› re"neries
Important!
› The use of Unior IMPACT sockets is recommended.
› We shall never exceed the requested torque starting point of the multiplier.

SKU L B A C
622815 270 75 80 63 428

710P
Measuring tape
: :
SKU Nm Nm D A C H
616804 1/2" (32mm) 3/4" 1300 960 5 : 1 108 126 210 180 7000
616805 3/4" (36mm) 1" 2700 2000 5 : 1 108 128 210 186 7000

› plastic double component casing
› with stop and clip
› preciseness to class ll
› metal measuring tape

SKU m d
612131 2 16 108
612132 3 16 131
612133 5 19 221
612134 8 25 450
612135 10 25 506
