23 TONS REMOTE HYDRAULIC CRIMPING HEADS

RM/RF PRE-ROUNDING DIES
Pre-rounding dies for TP-413 & TP-413H & EP-413
Application: For cable-shape reforming to be round.
ADAPTORS FOR RM/RF PRE-ROUNDING DIES
Adaptors for RM/RF type dies

AR-415 ADAPTOR
RF4151 RM4151 RF4152 RM4152 FOR 415 TYPE DIE USE

AR-416 ADAPTOR
FOR 416 TYPE DIE USE
RF4161 RM4161 RF4162 RM4162

Male Dies No. Female Dies No. For Aluminum Lugs Crimping
RM4151 RF4151 AL25
RM4152 RF4152 AL70
RM4161 RF4161 AL120
RM4162 RF4162 AL185

23 tons remote hydraulic crimping head
For aluminum ferrules crimping
Remote type needs to work with pump DF617 (SHORT)
TP-617H (Remote Type) DEEP INDENT DIES
Big size aluminum ferrules crimping
300-630mm deep indent crimping range LF617 (LONG)
2
23 tons output DEEP INDENT DIES

AR-617 ADAPTOR Inner Dia. A Inner Dia. B Inner C
FOR 617 TYPE DIE USE Model No. Code (mm) (mm) (mm) Stamped Info

DF6171 MA-400 40 30 122 AL300-400
DF6172 MA-630 47.2 39 122 AL500-630
LF6171 LA-400 40.4 28 231 AL300-400
LF6172 LA-630 47.4 37.2 230.3 AL500-630
