Attachments

アタッチメント

ダイスホルダー（ボルト手直し用）
■ Die Holders

品 番 φA φB C ダイスサイズ
Part No. (mm) (mm) (mm) Die Size 40
DHM5 20 7 8 M5 P0.8
DHM6 20 8 10 M6 P1.0 φ A φ B
DHM8 20 10 12 M8 P1.25
DHM10 25 12 14 M10 P1.25 μΠε C
%JF
˔Ϙϧτͷωδࢁ࠶ੜʹ࠷దͰ͢Ň
Suitable for re-threading.
タップホルダー
■ Tap Holders
品 番 φA B C 使用タップサイズ 20
Part No. (mm) (mm) (mm) Tap Size
TH-5 5.5 4.5 10 M 5 φA C
TH-6 6.0 4.5 10 M 6
TH-8 6.2 5.0 12 M 8 M4 B
TH-10 7.0 5.5 14 M10
TH-7/16 8.0 6.0 14 7/16UNF ιέοτ
4PDLFU
TH-12 8.5 6.5 17 M12
˔λοϓʢผചʣΛ૷ண͢Δ͜ͱͰɺωδΛཱͯͨΓŊ໨٧·Γͨ͠ωδͷ
͞Β͍࡞ۀ͕Ͱ͖·͢Ňλοϓ͸ࢭΊωδʢ. ʣͰ͔ͬ͠Γݻఆ͍ͯͩ͘͠͞Ň λοϓϗϧμʔ
λοϓ
Hold a tap fixed by M4 cap screw bolt tightly, and it is easy to operate for tapping and thread cleaning. A tap is not included. 5BQ 5BQ )PMEFS
ソケットアダプター
■ Socket Adapters
品 番 H1 H2
Part No. (mm) (mm)
SA0810 8 10
ˑ SA0812 8 12 40
ˑ SA1008 10 8
SA1012 10 12 ιέοτ
4PDLFU
SA1014 10 14 ιέοτΞμϓλʔ
4PDLFU "EBQUFS
ˑ SA1208 12 8
SA1210 12 10 H1 H2
SA1214 12 14
SA1410 14 10
SA1412 14 12
SA1417 14 17
SA1714 17 14
˔ϘϧταΠζͷҧ͏෦ҐͰ΋؆୯ʹ࡞ۀ͕ग़དྷ·͢Ň
It is easy to operate different bolt sizes.
タップホルダービット
■ Tap Holder Bits
品 番 φA □B φD タップサイズ λοϓ
Part No. (mm) (mm) (mm) Tap Size 5BQ
3BTH5M 5.5 4.5 12 M 5 φ A 55
3BTH6M 6.0 4.5 13 M 6 H6.35
3BTH8M 6.2 5.0 15 M 8 φ D
3BTH10M 7.0 5.5 15 M10
˔λοϓʢผചʣΛ૷ண͢Δ͜ͱͰɺωδΛཱͯͨΓŊ໨٧·Γͨ͠ωδͷ □ B 9
ɹ ͞Β͍࡞ۀ͕Ͱ͖·͢Ňλοϓ͸ࢭΊωδʢ. ʣͰ͔ͬ͠Γݻఆ͍ͯͩ͘͠͞Ň
Hold a tap fixed by M4 cap screw bolt tightly, and it is easy to operate for tapping and thread cleaning. A tap is not included.
ダイスビット（ボルト手直し用）
■ Die Bits
品 番 φD ダイスサイズ 75
Part No. (mm) Die Size H6.35
3B6MD75 16 M6 P1.0 φ D
3B8MD75 16 M8 P1.25
35 9
˔Ϙϧτͷωδࢁ࠶ੜʹ࠷దͰ͢Ň
Suitable for re-threading.
ˑҹ͸ࡏݿᷮগ඼Ͱ͢ɻ౎߹ʹΑΓड஫ੜ࢈ͱͳΔ৔߹͕͋Γ·͢ͷͰɺೲظ͸౎౓͓໰͍߹Θ͍ͤͩ͘͞ɻ 44
Attention to products marked "☆". They are not always in stock. Check the delivery time when ordering.
