Cutting value table

Length Length
Article No. mm Ø mm Ø mm Ø mm Ø mm Page Article No. mm Ø mm Ø mm Ø mm Ø mm Page
01 0 160 2.0 1.5 14 72 62 200 6.0 93
190 2.5 2.0 14 73 0 160 4.8 3.8 2.7 2.2 99
02 0 180 2.5 2.0 11 73 7 180 5.5 4.6 3.2 3.0 102
200 2.8 2.2 11 74 0 140 3.1 2.0 1.5 100
225 3.0 2.5 11 160 3.4 2.5 2.0 100
03 0 140 2.8 1.8 10 180 3.8 2.7 2.2 100
160 3.1 2.0 10 200 4.2 3.0 2.5 100
180 3.4 2.2 10 250 4.6 3.5 3.0 100
200 3.8 2.5 10 74 91 250 5.0 5.0 3.8 3.5 103
250 3.8 2.5 10 75 02/12 125 0.2 – 1.3 1.0 0.6 0.4 265
08 0 110 2.5 1.6 14 75 22 125 0.2 – 1.3 0.9 0.4 0.3 265
08 2 145 3.0 2.0 12 75 52 125 0.2 – 0.8 0.5 0.3 265
185 3.8 3.0 12 76 01/03/05/12 125 0.4 – 3.0 2.3 1.5 0.6 98
09 240 4.6 3.0 15 76 22 125 0.4 – 2.5 98
13 0 160 2.5 1.6 40 76 81 125 0.4 – 1.7 1.3 0.8 98
13 4 165 3.2 2.2 41 77 01 115 0.3 – 1.6 1.2 0.6 269
14 2 160 2.5 1.5 48 77 02 115 0.3 – 1.6 1.2 0.6 269, 270
19 0 130 2.2 1.6 52 120 2.0 1.4 1.0 0.6 271
25 01/03 125 2.2 1.6 55 130 0.3 – 2.0 1.5 0.8 269, 270
25 0/21/25/26 140 2.5 1.6 55 135 2.2 1.6 1.2 0.8 271
160 2.5 1.6 55 77 11/12 115 0.3 – 1.6 1.2 0.6 269, 270
26 1/26 2 200 3.2 2.2 56 77 21 115 0.3 – 1.3 1.0 269
50 0 160 1.8 86 77 22 115 0.3 – 1.3 1.0 269
180 2.0 86 77 32 115 0.3 – 1.3 1.0 0.5 269, 270
210 2.2 86 120 1.6 1.0 0.6 0.2 271
225 2.2 86 130 0.3 – 2.0 1.3 0.6 269, 270
250 2.2 86 77 41 115 1.3 0.8 269
51 01 210 2.2 86 77 42 115 0.3 – 1.3 0.8 269, 270
55 00 300 300 2.0 – 3.0 87 130 0.3 – 1.6 1.3 269, 270
61 0 200 1.0 – 6.0 4.0 3.5 3.0 110 77 52 115 0.3 – 1.0 0.8 0.5 269, 270
62 12 120 0.3 – 1.0 0.7 273 77 72 115 0.3 – 0.8 269, 270
64 0 115 2.0 1.0 0.6 272 77 82 130 0.3 – 1.6 1.3 269, 270
64 11/12 115 1.4 0.8 272 78 03/06/13 125 0.2 – 1.6 1.0 262
64 22 115 0.8 272 78 03 140 0.2 – 2.1 1.2 264
64 32 120 1.5 1.0 0.5 272 78 23 125 0.2 – 1.0 0.6 262
64 42 115 1.5 1.0 0.5 272 78 31/41 125 0.2 – 1.0 262
64 52 115 1.3 272 78 61/71 125 0.2 – 1.6 1.2 262
64 62 120 0.6 272 78 61 140 0.2 – 2.1 1.4 264
64 72 120 1.5 272 78 81/91 125 0.2 – 1.6 1.2 0.6 262
67 0 140 4.0 3.1 2.0 1.5 111 79 02 120 0.2 – 1.4 1.0 0.6 266, 267
160 4.5 3.4 2.5 2.0 111 79 02 125 0.2 – 1.7 1.3 0.7 266, 267
200 5.0 3.8 3.0 2.5 111 79 12 125 0.3 – 1.7 1.3 1.0 0.6 266, 267
68 01 160 4.0 2.8 2.3 111 79 22 120 0.1 – 1.3 0.8 266, 267
180 4.0 3.2 2.5 111 79 22 125 0.1 – 1.7 1.0 266, 267
200 4.0 3.5 2.8 111 79 32 125 0.2 – 1.5 1.1 0.6 266, 267
280 4.5 4.0 3.2 111 79 42 125 0.1 – 1.5 0.8 266, 267
70 110 3.0 2.0 1.2 96 79 52 125 0.2 – 1.3 0.9 0.5 266, 267
125 3.0 2.3 1.5 96 79 62 125 0.1 – 1.3 0.8 266, 267
140 4.0 2.5 1.8 96 95 6 190 4.0 2.5 178
160 4.0 3.0 2.0 96 99 0 200 1.8 1.4 88
180 4.0 3.0 2.5 96 220 2.4 1.6 88
71 160 5.3 4.4 3.2 3.0 104 250 2.4 1.6 88
200 6.0 5.2 4.0 3.6 105, 106 280 2.8 1.8 88
250 5.6 4.0 3.8 107 300 3.1 1.8 88
71 31 160 5.3 4.8 3.6 3.3 104 99 1 250 3.3 1.8 89
250 6.0 4.3 4.2 107 300 3.8 2.0 89

Wire classes

Tensile strength
Material examples Type of wire
N/mm 2 kp/mm 2
Copper, plastics soft 220 22

Nail, wire pin medium-hard 750 75

Wire rope strand, steel wire hard 1800 180

Spring steel wire piano wire 2300 230

Note
The maximum values always indicate the performance limit under the most favourable cutting conditions,
when the wire is placed as near as possible to the joint.

378 I CUTTING VALUES AND WIRE CLASSES
