SMD Precision Tweezers

optimised for electronic work with SMD
components
92 01 01
> When working on SMD components (SMD = surface mounted device):
the fine geometry of the SMD tweezers also allows work to be carried
out on electronic components that can be soldered directly onto the
circuit board using solderable connecting surfaces
> Handcrafted: polished edges and an excellent matt, scratch-free and 92 01 02
non-reflective surface
> For assembly work, laboratory processes, clean room environments,
circuit board repairs and reworking in the electronics industry
> High-quality premium stainless steel: high temperature resistance and
excellent corrosion resistance to most chemicals, salts and acids 92 01 03
> Antimagnetic to avoid electromagnetic damage
> The variety of designs and jaw types enables small components to be
held, positioned and controlled securely in confined spaces
> Also available as a set (92 00 03)
> Stainless steel
92 01 04

92 02 54

International EAN L x B x H Gripping Tips width
Article No. Code 4003773- mm surface Handles Finish Tweezers tip version A x B mm g
92 01 01 SM103.SA.1.KN 085522 115 x 10 x 11 45° smooth angled 45° positioning 0.33 x 1.6 15
92 01 02 SM107.SA.1.KN 085539 120 x 10 x 11 35° smooth double-angled 35° positioning 0.15 x 1.5 15
92 01 03 SM108.SA.1.KN 085546 120 x 10 x 11 smooth straight positioning 0.3 x 1.5 15
92 01 04 SM111.SA.1.KN 085591 115 x 10 x 11 45° smooth angled 45° positioning 0.5 x 1.5 15
92 02 54 SM115.SA.1.KN 054610 115 x 10 x 11 30° smooth angled 30° positioning 0.6 x 0.9 14

SMD Precision Tweezers ESD

DIN EN 61340 -5-1
92 08 78 ESD
> This allows to compansate in a controlled manner the differences
in potential between the operator and electronic components
> With a tested black epoxy resin coating with a surface resistance
between 10 and 10 ohms
4
9
> Stainless steel

EAN L x B x H Gripping Tips width
Article No. International Code 4003773- mm surface Handles Finish Tweezers tip version A x B mm g
92 08 78 ESD SM109.SA.NE.B.KN 054634 118 x 10 x 12 45° smooth angled 45° positioning 0.5 x 2.5 15

ELECTRONICS PLIERS AND PRECISION TWEEZERS I 287
