General workshop equipment General workshop equipment

Tool trolleys i Work benches i/ Tool cabinets

167-3 S Service trolley i 167 T Multi table i

Made in Germany S/ Made in Germany S/
• Rectangular perforation on the side panels offer individual • Sturdy ram protection on all important struts for protecting
fastening options important areas, e.g. body and high quality rims
• Adjustable in 15 height positions (middle tray) • Table can be collapsed downwards by 90°
• More layers and anti-slipping mats (2x 180-38) are optionally available • Adjustable in 15 height positions (steps: 25 mm)
• Robust sheet steel construction, loading capacity per tray: 50 kg • Robust welded design
• Large ball-bearing wheels (x 100 mm), 2 swivel castors • Ball-bearing wheels (x 50 mm),
(1 x with double stop), 2 fixed castors 4 swivel castors, 2 castors with brake
• Thread guard – protects the bearings against dirt and threads • Easy manoeuvrability, even with high dynamic load
• Easy manoeuvrability, even with high dynamic load • Grey non-marking elastic tyres enable smooth movement
• Grey non-marking elastic tyres enable smooth movement • Fits under vehicles with a ground clearance greater than 130 mm
• Sturdy handle, firmly attached to the trolley • Loading capacity of table: 35 kg
• For HAZET Safety-Insert-System, 2-component soft foam insert • Delivery, flat packed (h x w x d: approx. 110 x 930 x 780 mm)
• Loading capacity per tray: 50 kg • Accessories 112/11 ∙ 179-35 ∙ 179 N-35 ∙ 180-24 ∙
• Side fastening options for comprehensive HAZET accessories range (optional) 180-35 only together with 167T26
• Colour: HAZET blue / black side panels • Total loading capacity (dynamic): 150 kg
• Total loading capacity (dynamic): 150 kg • Loading capacity (static): 150 kg
• Loading capacity (static): 150 kg • Colour: HAZET blue

YouTube Clip

The following accessories are available separately: The following accessories are available separately:
1 Designation 1 Designation 1 Designation 1 Designation

112/11 Tool holder 50 179 N-35 Can holder 55 112/11 Tool holder 50 179-35 Can holder 55
161 N-3 D/2 Cable drum 52 180-24 Document holder 57 162 C-5 Container for small parts 54 179 N-35 Can holder 55
179-35 Can holder 55 180-34 Holder for paper reel 57 167 T 23 Storage board 54 180-24 Document holder 57
179 N-33 Paper bin 54 180-35 Can holder 55 167 T 26 Perforated tool panel 54 180-35 Can holder 55

1) Accessories only together with 167T-26
1 L x W x H 6 4 1 L x W x H 6 4
mm
mm
167-3 S 888 x 541 x 899 27 207206 167 T 1) 773 x 740 x 1345 17.9 210503
46 Errors excepted Components and spare parts from page 500 to 509
