Specialty tools

Body and interior equipment – Car body repair

1961 Sheet metal profile snips 1934 Car body file holders

• Compact design facilitates working in confined spaces and cutting 4A Made in Germany A
the smallest of contours • Adjustable, with tightening screw
• With 1 file blade 1934-4
• For figure cutting and straight cuts • For flat file blades
• For sheet thickness up to 1.2 mm (600 N/mm ) HAZET 1934-1 up to -5
2
• Edge length: 20 mm G
• Lever transmission system for a minimum effort
• For small radii and working in areas
with restricted access 1 4
• Shear head drop-forged K
• Induction-hardened cutting edges with grind 1934 355 008018
• Ergonomically shaped HAZET 2-component
plastic handle covers (blue/black)
1934 N Car body file holders
Made in Germany A F
• Made of wood
• Without file blade

1961 L-3 1961 R-3 D

1 K 4

• Left hand cutting 1934 N-1 1934 N-2
1961 L-3 180 176533
• Right hand cutting 1 4
1961 R-3 180 176540 K
• For flat file blades 1934-1 up to -5
1963 Hand riveting tool 1934 N-1 525 008155 R
• For half-round (hollow) file blades 1934-7
• Application: Safe and fast rivet joints A/ 1934 N-2 525 008179
• For blind rivets made of aluminium up to 5 mm x,
steel up to 4 mm x, stainless steel up to 3.2 mm x
• Rivet is fixed automatically when inserting the nose piece 1934 Car body file blade
• Quick changing of nose pieces due to knurling, no tools needed
• Rivet snaps off with little effort • Flat A
• Due to the design, the slitting process of the • Milled, diagonal cut
rivet pin is optimally damped • Teeth (cut):
• Patented rivet plug gauge 1 = coarse 1934-1 C
• Assembly tool in the handle 2 = medium 1934-2
3 = fine 1934-3
• For file holders HAZET 1934 and 1934N-1
• DIN 7264 form A

1 K 4
1963 N-1 255 187447
O
• Flexible use due to 360° rotation rivet head A 1 K 4
• Application: Riveting various materials such as 1934-1 350 008025
350
1934-2
008063
metal, aluminium, plastic, leather, etc. 1934-3 350 008070
• 4 replaceable nose pieces in the body of the pliers
• Assembly tool in the handle
• Patented rivet plug gauge • Flat A
• For aluminium rivets x 2.4 ∙ 3.0 ∙ 3.2 ∙ 4.0 ∙ 4.8 ∙ 5.0 mm ∙ ⁄32″ ∙ • Milled, curved cut
3
3
1 ⁄8″ ∙ ⁄32″ ∙ ⁄16″ • Teeth (cut):
5
3
Steel rivets x 2.4 ∙ 3.0 ∙ 3.2 ∙ 4.0 mm ∙ ⁄32″ ∙ ⁄8″ ∙ ⁄32″ 1 = coarse 1934-4 A
1
5
3
1
Stainless steel rivets x 2,4 ∙ 3.0 ∙ 3.2 mm ∙ ⁄32″ ∙ ⁄8″ 2 = medium 1934-5
• For file holders HAZET 1934 and 1934N-1
• DIN 7264 form A
U
1 K 4
1 K 4 1934-4 350 008087
1963-2 290 232864 1934-5 350 008094
