Specialty tools Specialty tools

Chassis – Cardan shafts Chassis – Wheels / Tyres

4935 Drive shaft disassembly / assembly set 900 SZ 1/2″ Impact socket set

Made in Germany C
• Application: Disconnecting the drive shaft joint and pulling Made in Germany % 8 F/
in the shaft through the wheel hub with just one tool • Application: Operation of drive and cardan shaft screw
• Disconnecting the drive shaft joint from the shaft using the sleeves or spindles connections,
G • Pulling in the drive shaft through the wheel hub on vehicles where e.g. Ä 24 mm for VW Touran model year 2006 → and Passat C
together with HAZET sliding hammer 4797-1 (not included in delivery)
Ä 30 mm for axle shaft nut on VW Golf 4 ∙ Polo and New-Beetle ∙ AUDI TT 1.8 ∙
the drive shaft is very difficult to pull through the wheel hub
Ä 32 mm operation of the cardan shaft screw connection in the wheel hub on VW
• Suitable for all vehicle brands ŠKODA Octavia ∙ Superb ∙ Fabia
• For drive shafts with outside and inside thread Touareg model year 2003 →
• Contents (12-piece set): Ä 36 mm for axle shaft nut on BMW 3 Series ∙ 5 Series ∙ 7 Series ∙ Z3 ∙ M3
2 spindles (M14, M16) for pulling the drive shaft through the wheel hub or for VW Polo model year 2001 → ∙ Golf Plus 1.9 TDI model year 2005 → ∙ SEAT Ibiza
disconnecting the articulated joint from the shaft in case of articulated joints with model year 2002 →
Wheel hub screw connection on the front axle RENAULT Twingo 3 ∙ SMART
inside thread (453) Fortwo / Forfour model year 2014 →
2 sleeves for supporting on wheel hub
1 spindle nut • Surface: phosphatized, oiled
F 7 screw sleeve adapters • DIN 3129, ISO 2725-2
– M16 x 1.5 (VAG ∙ MAZDA)
– M18 x 1.5 (Volvo ∙ SUZUKI ∙ OPEL/VAUXHALL)
– M20 x 1.5 (MERCEDES-BENZ ∙ VAG ∙ MITSUBISHI ∙ MAZDA)
– M22 x 1.5 (FIAT ∙ PSA ∙ BMW ∙ FORD ∙ OPEL/VAUXHALL ∙ HYUNDAI)
– M24 x 1.5 (RENAULT ∙ BMW ∙ MERCEDES-BENZ ∙ OPEL/
VAUXHALL ∙ MAZDA ∙ HONDA ∙ VAG)
– M27 x 1.5 (PSA ∙ BMW ∙ FORD)
– M30 x 1.5 (MERCEDES-BENZ ∙
PSA ∙ BMW) 900 SZ • % • 8
24 • 30 • 32 • 36
D 1 è 4
900 SZ/4 4 156375
1/2″ Impact socket set ∙
2521 S with special profile

Made in Germany 8 F
R • Optimised special profile for damage-free attachment of the
flat-head lightweight nuts
• Application: For the operation of lightweight nuts with special profile for rear axle
screw connections / camber adjustment
e.g. AUDI A4 B9 model year 2015→ ∙ A6 C8 model year 2018→
• Surface: phosphatized
YouTube Clip
1 è 4
C 4935-11/12 12 217434

Spindle nut for 4925-2505/9 ∙ 4925-67/2 ∙ 4927-2701/4 ∙ 4935-11/12
4925-11 – 168590
Spindle for 4935-11/12
4935-111 – 217571
4935-112 – 217564
Extraction sleeve M16 x 1.5
for AUDI ∙ SEAT ∙ ŠKODA ∙ VOLKSWAGEN ∙ MAZDA 1 K G H c 4
O 4935-1116 – 217588 2521 S-1 40 31 30 15 246571
Extraction sleeve M18 x 1.5
for Volvo ∙ SUZUKI ∙ OPEL/VAUXHALL
4935-1118 – 217601
Extraction sleeve M20 x 1.5
for MERCEDES-BENZ ∙ AUDI ∙ SEAT ∙ ŠKODA ∙
VOLKSWAGEN ∙ MITSUBISHI ∙ MAZDA
4935-1120 – 217618
Extraction sleeve M22 x 1.5
for FIAT ∙ PEUGEOT ∙ CITROËN ∙ BMW ∙ FORD ∙
A OPEL/VAUXHALL ∙ HYUNDAI – 217625
4935-1122
Extraction sleeve M24 x 1.5
for RENAULT ∙ BMW ∙ MERCEDES-BENZ ∙ OPEL/VAUXHALL ∙
MAZDA ∙ HONDA ∙ AUDI ∙ SEAT ∙ ŠKODA ∙ VOLKSWAGEN
4935-1124 – 217632
Extraction sleeve M27 x 1.5
for PEUGEOT ∙ CITROËN ∙ BMW ∙ FORD
4935-1127 – 217656
Extraction sleeve M30 x 1.5
U for MERCEDES-BENZ ∙ PEUGEOT ∙ CITROËN ∙ BMW 217663
4935-1130
–
Clamping sleeve for 4935-11/12
4935-1139 – 217670
4935-1146 – 217687
