Specialty tools

Brakes

4968 Brake bleeding wrench 2191 Tube flaring tool set

Made in Germany c R Made in Germany R/
• Equal hexagon size on both sides • For metal tubes and pipes with a wall thickness of 0.7 to 1.0 mm
pipe X 4.75– 10 mm
• Application: Brake bleeding without dismounting the wheels,
replacement of wheel brake cylinder, master brake • Application: Making open (F) or twin (E) flares in accordance with DIN 74234,
cylinder and the tube connections standard 90° and 180° flares G
• Bent and offset For flares on rolled and drawn pipes
• Surface: chrome-plated • Replaceable, hinged gripping jaw
Attention: for plastic-coated brake lines use
HAZET 2193/4K
• Special cast steel
• Plastic box 165-L (1/3)
• 2-component soft
foam insert
F
1 S K 4
4968- 7 7 190 085705
4968- 8 8 208 085699
4968- 9 9 208 085682
4968-10 10 236 085712
4968-11 11 236 085729

4963 Specialty tool for brakes D
Made in Germany R
• Push and turn-part with carbide coating layer in the front working area

• Application: Installation and removal of the spring plate and
the holding device of the brake linings on drum brakes
• On e.g. VW ∙ SEAT ∙ ŠKODA ∙ OPEL/VAUXHALL
and RENAULT with rear drum brakes
• Plastic handle
• Surface: chrome-plated 2191-2 2191 R
2181 N-1 2191-4 • 2191-5
2191-6 • 2191-8
2191-9 • 2191-10

2191-1 2191-3 2191-90

1 L x W x H è 4
mm
C
2191/12 K 290 x 173 x 50 12 013890
2191 Basic unit
1 K 4
4963-1 237 050383 Made in Germany R
• Holding the gripping jaw 2191-1
4964 Draw spring assembly tool

Made in Germany R O
• Hook with T-handle
• Application: Installing and removing the draw spring
of hand brake shoes (rear disc brake)
• On e.g. MERCEDES-BENZ passenger cars as well as Sprinter
VW Crafter model year 2006 → 2016 and LT 1996 → 2006
• 2-component T-handle
• Surface: chrome-plated 1 4
A
2191 013784
2191 Gripping jaw
Made in Germany R
• Socket in basic unit 2191
• For E, F, 90° and 180° flares
• 4.75 up to 10 mm
U

1 K 4 1 mm 4
4964-1 A 162 249299 2191-1 4.75 – 5 – 6 – 8 – 9 – 10 mm 013791
