Page 448 - HAZET哈蔡特2024英文样本

Specialty tools Specialty tools

Brakes Brakes

4969 Pneumatic brake bleeding set Product applications
Brake piston readjusting sets
• Brake bleeder for the extraction of brake fluid on wheel brake R hazet.de  Service  Tool Finder
cylinders / brake callipers  Brake piston readjusting sets
C For Smartphones with QR reader (app)
• Also suitable for ABS brakes (Caution: Always
follow manufacturer‘s specifications)
G • By means of compressed air, the integrated Venturi system 4970 Brake piston readjusting
creates a vacuum, with which the brake system is bled
• Including universal plastic nozzle, suitable for all vehicles tool set ∙ pneumatic
• Clear transparent brake bleeding hose enables easy visual check • Universal application thanks to 3-piece adapter set
• Air consumption: 180 l/min / working pressure: 6 to 8 bar R
• Including coupler plug, nominal size 7.2 • Application: Readjusting brake pistons on floating calliper
• Contents: systems with or without locking device for hand brakes
1 brake bleeding device (container capacity 0.75 l) • For clockwise and anti-clockwise brake pistons
1 refill container with fixed nozzle • Largest possible recovery movement of the piston rod as far as into
1 refill container with flexible nozzle the housing – operation also when brake piston is extended far
F (container capacity: 1 litre each) • For smallest brake callipers MINI ∙ BMW 1 Series to
BMW X7 (largest brake calliper at present)
• Pneumatic support together with swivelling rotary level
allows effortlessly easy and quick resetting
• It is possible to simultaneously press and turn or only press the brake
piston after the brake pads on disc brake systems have been replaced
• Included adapter set 4970P-02/3 ensures flexible holding of pressure
plates from other manufacturers available on the market, e.g:
– Inside hexagon adapter Ä 13 mm for HAZET
pressure plates of product group 4970
– 10 mm ( ⁄8″) i adapter to connect OEM special adapters
3
D – 2-pin adapter for, among others, VIGOR ∙ SW-Stahl ∙ KS-Tools ∙ BGS ∙ Kunzer
e.g. all current MINI and BMW adapters ∙ SW-Stahl
• In case with soft-foam insert and storage option for additional adapters
• Including operating instructions

R 1 è 4

4969-1/3 3 149445

4968 Hook set
• Application: Securely hanging dismounted components, e.g. R
brake callipers, avoids damage to brake hoses, lines etc.
C • Universal application
• Hook x: 7 mm
• Surface: immersion-lacquered

YouTube Clip
O 1 K 4

4968/2 H 190 221820

4970 Basic unit

Made in Germany R
• Application: Readjusting brake pistons on floating 4970 P-02/3
A calliper systems with or without
locking device for hand brakes

• Basic unit 1 è 4
• Thrust bearing avoids damaging the dust boot
• With additional outside 4970 P-1/4 4 232970
hexagon Ä 13 mm for flexible application Adapter set
of operating tools, e.g. ratchets
• For adapting pressure plates from different
manufactures to basic unit HAZET 4970P-1:
• Inside hexagon adapter Ä 13 mm for HAZET
U • 10 mm ( ⁄8″) outside square adapter to connect OEM special adapters
pressure plates of product group 4970
3
e.g. all current MINI and BMW adapters ∙ BMW 1 Series up
1 4 • 2-pin adapter for, among others, VIGOR ∙ SW-Stahl ∙ KS-Tools ∙ BGS ∙ Kunzer
to BMW X7 brake calliper (currently largest calliper)
4970-1 088874 4970 P-02/3 3 234929
446 Errors excepted Components and spare parts from page 500 to 509
