Specialty tools

Oil service

3702 1/2″ Oil service screwdriver socket 198-10 Engine oil filling funnel
C
D
Made in Germany a8 D
• For the oil filler and oil drain plug 1 ] è 4
gearbox, differential, oil pan
• Surface: chrome-plated For VW group vehicles of the MQB platform G
• 8 mm inside square • Necessary due to a smaller diameter of the oil filler plug
• For e.g. MERCEDES-BENZ type 415 (Citan) ∙ • AUDI A3 (8V) ∙ VW Golf 7 ∙ SEAT León (5F) ∙ ŠKODA Octavia 3
type 177 (A-Class) ∙ type 247 (B-Class) with OM
208 engine • 2-part set, contents, special funnel 198-9 ∙ oil filling adapter 198-7
RENAULT • Made in Germany
198-9/2 1 2 186396
• Bayonet fitting, universal use e.g. on AUDI ∙ VW ∙
SEAT ∙ ŠKODA ∙ MERCEDES-BENZ etc.
• 2-part set, contents, special funnel 198-9 ∙ oil filling adapter 198-10
1 S K 4 • Made in Germany
3702 8 36 018918 198-10/2 1 2 187218 F
• Oil filling adapter for engine oil filling funnel 198-9, can be used in vehicles of
the VW Group MQB platform
3703 Oil service wrench AUDI A3 (8V)
VW Golf 7
SEAT León (5F)
Made in Germany a D ŠKODA Octavia 3
• For the oil filler and oil drain plug • Made in Germany
gearbox, differential, oil pan 198-7 – – 187256
on various French passenger cars
• 8 and 10 mm outside square • Special funnel made of sturdy plastic D
• Surface: chrome-plated • Combination possible with oil filling adapters (198-7 ∙ 10 ∙ 13 ∙ 14 ∙ 15 ∙ 16 ∙ 17 ∙
18 ∙ 19)
also together with angle connection piece 198-12
(adapter and angle connection piece optionally available)
• Made in Germany
198-9 1 – 187249
• Adapter with bayonet fitting for engine oil filling funnel
198-9, can be universally used e.g. on AUDI ∙ VW ∙
SEAT ∙ ŠKODA ∙ MERCEDES-BENZ ∙ BMW etc.
• Made in Germany
1 S K 4 198-10 – – 187263 R
3703 8 x 10 233 018932 • Angle connection piece for hard to reach oil filling openings
• Made in Germany
198-12 – – 206766
198-10 Engine oil filling funnel • Oil filling adapter for engine oil filling funnel 198-9, can be used in engines:
OPEL/VAUXHALL ∙ RENAULT: G9Q-T-U
NISSAN ∙ OPEL/VAUXHALL ∙ FIAT ∙ RENAULT: R9M
Made in Germany D MERCEDES-BENZ: C-Class type 205, GLC type 253 with OM 626, Vito type
• Replaceable adapter made of aluminium 447 with OM 622
DACIA: H5F ∙ K7M ∙ K4M ∙ D4F ∙ K7J ∙ K4M ∙ H4B ∙ D4F
• Easy installation on the engine of the vehicle • Made in Germany C
• Ensures the necessary slow, controlled filling of engine oil for some 198-13 – – 206773
engines – saves time: other work can be done while the oil is draining • Oil filling adapter for engine oil filling funnel 198-9, can be used in
• Replaceable aluminium adapters for many common vehicle models MERCEDES-BENZ engine
• Flexible use due to plug system M270: A-Class type 176 ∙ B-Class type 246
• With optional angle connection piece 198-12, also for M271: C-Class type 203, 209, 204 ∙ E-Class type 211,
hard-to-reach oil filling openings 212, 207 ∙ SLK type 171, 172 ∙ Sprinter type 906
• Special funnel made of sturdy plastic • Made in Germany
198-16 – – 206803
• Oil filling adapter for engine oil filling funnel 198-9, can be used in
MERCEDES-BENZ engine O
OM 654: A-Class, type 177 ∙ B-Class, type 247 ∙ C-Class, type 205 ∙ E-Class,
type 213 ∙ V-Class, type 447
M 282: A-Class, type 177 ∙ B-Class, type 247
• Made in Germany
198-17 – – 206827
• Oil filling adapter for engine oil filling funnel 198-9, can be used in
MERCEDES-BENZ engine
OM 607: type: 415 Citan, 176 A-Class, 246 B-Class,
117 CLA, X156 GLA ∙ RENAULT engine K9K
• Made in Germany A
198-18 – – 219179
• Oil filling adapter for engine oil filling funnel 198-9, can be used in 1.5 TSI VW
Group engine
AUDI A1 model year 11/2018 → ∙ A3 model year 05/2017 → ∙ Q2 model
year 11/2018 → ∙ Q3 model year 09/2018 →
198-10 198-12 198-13 198-16 SEAT Arona model year 11/2017 → ∙ Ibiza model year 08/2017 → ∙ León
3 model year 09/2018 → ∙ Tarraco model year 10/2018 → ∙ Ateca model
year 10/2018 →
ŠKODA Karoq 07/2017 → ∙ Octavia 3 model year 08/2017 → ∙ Superb 3 model
year 10/2018 →
VW Arteon model year 11/2018 → ∙ Golf
7 model year 03/2017 → ∙ Golf Sportsvan 10/2017 → ∙ Polo 6 model U
year 09/2017 → ∙ T-Roc model year 11/2017 → ∙ Passat B8 model
year 10/2018 → ∙ Touran 2 model year 10/2018 →
198-17 198-18 198-19
• Made in Germany
B 198-19 – – 226993
Components and spare parts from page 500 to 509 Errors excepted 439
