Specialty tools

Oil service

Oil service

Overview of oil filter wrenches

1 Design Oil filter Oil filter wrench outside Insert depth Total Drive Page
t
dimensions
points / grooves
t Wrench mm height mm y j G
2168-46 6-Point 46 59 15 29 – 7 485
2169 14-Point 74 82 30 52 27 7 435
2169-1 15-Point 92 102 19 48 27 8 435
2169-6 16-Point 86 97 44 55 24 8 436
2169-7 14-Point 64 76 23 43 24 8 436
2169-8A 15-Point 74 105 – 38 – 8 437 F
2169-9 15-Point 105 119 36 52 24 8 487
2169-10 14-Point 74 82 20 42 27 7 435
2169-11 14-Point 84 97 30 48 24 8 436
2169-12 15 Grooves 74 107 – 38 – 8 437
2169-13 14-Point 80 107 – 38 – 8 437
2169-14 14-Point 72 104 – 38 – 8 437
2169-15 8-Point 75 105 – 38 – 8 437 D
2169-32 6-Point 32 43 18 30 – 7 436
2169-36 6-Point 36 49 15 29 – 7 436
2169-66 6 Grooves 66 76 23 43 24 8 436
2169-76 6 Grooves 76 85 21 42 24 8 436
2169-76B 6 Grooves 76 85 21 42 24 8 436
2169-76K 6 Grooves 76 85 14 34 24 8 436
R
2169-86 9 Grooves 86 97 24 44 24 8 436

Product applications 2169 Oil filter wrench
Oil service
hazet.de  Service  Tool Finder C
 Oil service 7 D
C For Smartphones with QR reader (app)
1 h t 4
2169 Oil filter wrench C
• Operating the oil filter housing cap when changing the oil filter element
Made in Germany 7 D on MAZDA 3 with 2.0 l engine and 6 with 1.8 – 2.0 – 2.3 l engines
• Application: Operating oil filters and oil filter housing caps • Flat style: continuous 14-point profile up to the edge
• 14-point Ä 74.4 mm 2169-10 27 82 108831
• j Drive 10 = /8″ or
3
outside hexagon: 27 mm
Made in Germany 8 D
• Optionally, j drive 12.5 = /2″ or
1
outside hexagon 27 mm
• Application: Operation of oil filters (KNECHT and MAHLE filters) O
15-point Ä 92 mm
• For e.g. VW ∙ AUDI Passat 1.9 TDi ∙ 2.8 l ∙ CHRYSLER 300 M ∙ PORSCHE ∙
OPEL/VAUXHALL ∙ RENAULT ∙ FORD Focus 1.8 Di model year 08/1999 → ∙
1.8 TDi model year 10/1998 → ∙ Maverick 2.7 TD ∙ Mondeo 2.5 l ∙ MITSUBISHI ∙
NISSAN ∙ ALFA-ROMEO ∙ HONDA ∙ Volvo ∙ MAN (commercial vehicles) F 2000

1 h t 4 A

• For MANN and KNECHT filters ∙ OPEL/VAUXHALL Longlife filters
e.g. for MERCEDES-BENZ passenger cars with 2.2 l CDI
engine ∙ M 102 ∙ M 103 ∙ M 104 ∙ M 110 ∙ M 111 ∙ M 119 ∙ M 120 ∙ M 613 ∙
Sprinter ∙ 2.2 l Turbo model year 2006 → ∙ diesel engine OM 651
AUDI A4 2.0 model year 2002 → ∙ A4 4-cylinder petrol engines model
year 12/2007 →
BMW passenger cars ∙ BMW motorcycles ∙ K-models = K 75-1100 LT ∙ Model
series F and K
VW Passat 1.9 TDI pump injector ∙ Passat B7 1.4 ∙ 1.8 ∙ 2.0 l TSI ∙ Golf Plus
2.0 model year 2005 → ∙ Golf 6 1.6 l and 1.2 / 1.4 / 1.8 / 2.0 l TSI ∙ Golf 7
1.2 - 1.4 l TFSI ∙ Polo 5 1.2 l – 1.4 l TSI ∙ Tiguan model year 2007 → 1.4 l TSI U
(110 kW) 2.0 l TSI
as well as FORD ∙ OPEL/VAUXHALL ∙ PORSCHE ∙ PEUGEOT ∙
CITROËN ∙ RENAULT ∙ NISSAN ∙ TOYOTA ∙ MAZDA etc. 1 h t 4
2169 27 82 013340
B 2169-1 27 102 013357
Components and spare parts from page 500 to 509 Errors excepted 435
