Workshop tools · Safety at work Workshop tools · Safety at work

Diagnostics / Borescope technology Diagnostics / Borescope technology

4812 HD touchscreen video borescope set 4812 HD swivelling probe 180°,

• Improved accuracy of detail thanks to HD camera K/ X 3.9 mm, front camera
• Touchscreen colour display with Li-Ion battery and magnetic holder • Improved accuracy of detail thanks to HD camera K
• Smaller probe diameter 3.9 mm
• 127 mm (5 inch) touch display, readable in sunlight
• Display resolution: 800 x 480 pixels • Compatible with basic unit 4812-23G and 4812-11G
• 10-level brightness setting (5 + 5 boost) • Including control unit to operate articulation,
• Zoom: 3 x video recording, brightness control
• Recording in 3 different time loops • Bending radius only approx. 35 mm
• Image format (jpg): 1920 x 1080 pixels (-30% compared to conventional designs)
• Video format (MP4): 1920 x 1080 pixels • High mobility due to bilateral articulation
• Negative display of the camera image • Full swivel up to 180° on both sides enables e.g.
• Data transfer: USB-C a real reverse view onto valves in the cylinder head
• HDMI port for video output • Front camera
• Video output: micro HDMI • Dimmable 2 x LED light source
• Rechargeable battery: Li-ion battery • Digital interface to basic unit: USB-C
• Charging time 3.5 h • Viewing angle (FOV): 90°
• Operating time when fully charged: 4 hours • Depth of focus (DOV): 10 – 100 mm
• Operating temperature: 10°C up to 50 °C • Resolution: HD
• Operating humidity of up to 90 % (non-condensing) 1280(H) x 720(V) pixels
• IP protection rating (basic unit): IP54 • Compression format: H264
• Built-in microphone • Operating temperature:
-10°C up to 60 °C
• Compatible with HAZET HD probes 4812-23AF and 4812-11FS • Probe protection rating: IP67
• Weight: 705 g • Weight: 307 g
• Dimensions: 162 x 128 x 46 mm • Improved accuracy of detail
• Compact design thanks to HD camera
• Easy to handle • Diagnosis of cavities for
• Swivelling magnetic base: 180° adjustable damage assessment
• Thread to hold a tripod screw connection (1/4″) in the magnetic base • Image format: Jpeg
• Reset button • Video format: MOV
• Display of battery capacity • Protection rating probe:
• Auto Power Off in 4 different times optional IP67 (when connected)
• Record videos (MOV format) and photos (JPEG format) • Probe cable: 1 m
• Image format: JPG, 1920 x 1080 pixels with optional watermark and timestamp • Dimensions: 35.4 mm x 51.1 mm
• Video format: MP4, 1920 x 1080 pixels with optional 2589 mm (W x H x L)
watermark, timestamp and audio
• Addition of own logos as watermark possible (160 x 160 pixels)
• Mirroring of the camera image
• Designation of photos on the touchscreen
• Creating folders on the touchscreen
• DC power adapter: 5 V / 3 A
• Charger: USB charging adapter DC-5 V / 3 A 1 4
• 28 menu languages can be selected
• Use of the system as a card reader / camera via USB connection to PC. 4812-23 AF 249602
PC software download
• L-Boxx 190 L-136
4812 Video borescope
• 4.9 mm x micro lens K
• Switching function viewing direction 90° + 0°
• Instant replay of video or photos at TFT monitor
• Show and hide date and time easily
• Automatic switch-off to save energy
• Viewing angle: 56°
• Depth of focus: 10–60 mm
• Resolution: QVGA (320x240 pixels)
• Improved connection between probe and housing (metal)
adapter for using older probes: 4812-20
• One-hand operation
2nd generation probe:
• Improved illumination with the 90° function
• Improved illumination power of LED
• Simplified application
• Improved quality of
the probe coating
• Probe protection
rating IP 67
Included in delivery
• 1 m probe cable with
4.9 mm x micro lens
and LED light sources
• Operating panel
• Hook including magnet
• SD card: 4 GB storage capacity
• 4 x AA batteries
• Plastic box

1 è 4
4812-23/5 AF 5 249824 B
