P. 395

Workshop tools · Safety at work

                                    Diagnostics / Borescope technology

                                         Diagnostics / Borescope technology


        1992 Thermal camera                                   4812 HD video borescope set

        •  Automatic hot, cold and central point measurement   KR  •  Improved accuracy of detail thanks to HD camera
          •  Image sensor: Vanadium oxide uncooled focal plane arrays (FPA)    •  Light boost and integrated reflection reduction
        •  Refresh rate: 25 Hz                                •  Luminous source: 5 dimming LEDs for optimum lighting
        •  Thermal sensitivity (Noise Equivalent Temperature   •  Optional recording in different time loops
         Difference, NETD): < 40 mK (0.04° C)                 •  Zoom: 1.5 x and 2 x
        •  Measuring accuracy maximum (±2° C ∙ ±2%): Ambient temperatures   •  Image format (jpg): 1920 x 1080 pixels
         15° C – 35° C / Object temperatures above 0° C       •  Video format (MP4): 1920 x 1080 pixels
        •  Field of view: 37.2° x 50°                         •  Mirroring of the camera image
        •  Record videos                                      •  Negative display of the camera image
        •  Visual camera: 3264 × 2448 pixels (8MP)            •  Data transfer: USB-C
        •  Screen size: 3.5 inch LCD touchscreen              •  Video output: micro HDMI
        •  Display resolution is 640 x 480 pixels             •  Operating temperature: 10°C up to 50 °C
        •  Thermal (or IR) resolution: 256 x 192 pixels       •  Operating humidity of up to 90 % (non-condensing)
        •  Temperature measuring range: -20 °C to 400 °C (-4 °F to 752 °F)  •  IP protection rating (basic unit): IP54
        •  Battery life: up to 4 hours                        •  USB interface can be used as a power source when no batteries are inserted
        •  Image modes: Thermal ∙ Optical ∙ Fusion ∙ PIP (picture in picture)  •  Compatible with HAZET HD probes 4812-11FS and 4812-23AF
        •  Digital zoom: 1x to 4x                             •  Power source: 4 x AA battery
        •  Storage medium: EMMC 16 GB (included in delivery) ∙ up   •  Weight: 370 grams without batteries
         to 60000 images or 10 hours of video material        •  Dimensions (L x W x H): 276 x 123 x 54 mm
        •  Additional features: LED light ∙
         microphone ∙ buzzer                                  •  Compact design
        •  Hand strap                                         •  Easy to handle
                                                              •  Eyelet on the battery compartment for mounting a hand strap (drop guard)
                                                              •  Thread to hold a tripod screw connection (1/4″)
                                                              •  Reset button
                                                              •  Auto Power Off function 3-way adjustable
                                                              •  Record videos (MOV format) and photos (JPEG format)
                                                              •  Image format: JPG, 1920 x 1080 pixels with optional timestamp
                                                              •  Video format: MP4, 1920 x 1080 pixels with optional timestamp
                                                              •  29 different menu languages can be selected
                                                              •  Use of the system as a card reader / camera via USB connection to PC
                                                               PC software download
                                                              •  Compatible with HAZET HD probes 4812-11FS and 4812-23AF
        1                  L x W x H           4              •  Plastic box
                                                              5-piece set in plastic case:
                             mm
        1992-2            139 x 85 x 24        249435         •  Basic unit 4812-11G
                                                              •  HD probe 4812-11FS
                                                              •  SD card with 32 GB storage capacity
              HD probe X 4.9 mm, front                        •  Micro HDMI cable (A to D) 1.8 m
        4812  and side camera                                 •  USB-C cable (A to C) 1 m
                                                              •  USB-C cable (A to C) 1 m
        •  Improved accuracy of detail thanks to HD camera   K
          •  Compatible with basic unit 4812-11G and 4812-23G
        •  Semi-flexible probe enables guidance through cavities
        •  Front and side camera switchable (0° and 90°)
        •  Dimmable 5 x LED light source for front camera
        •  Dimmable LED light source for side camera
        •  Digital interface to basic unit: USB-C
        •  Viewing angle (FOV): 90°
        •  Depth of focus (DOV): 10 – 100 mm
        •  Resolution: HD 1280(H) x 720(V) pixels
        •  Compression format: H264
        •  Operating temperature: -10°C up to 60 °C
        •  Probe protection rating: IP67
        •  Weight: 137 g
        •  Image format: Jpeg
        •  Video format: MOV
        •  Protection rating probe:
         IP67 (when connected)
        •  Probe cable: 1 m
        •  Dimensions: 1121 mm x 18 mm (L x W)












        1                                      4              1                     è                4
        4812-11 FS                             249565         4812-11/5 FS           5               249572

        Components and spare parts from page 500 to 509                                         Errors excepted  393
