TEST INSTRUMENTS
MT-4617LED
LED Light Intensity Meter
DESCRIPTION: LED Light Intensity Meter measures all light produced by all visible colors
of LED, fluorescent lamp, metal halide lamp, high‑voltage sodium lamp and electric
incandescent lamp. Built‑in precision diode sensor and color correction filter for indoor
use. Dual‑scape meter provides both digits and analog bar graph display. Auto and manual
range provide relative and peak value measurement. User‑friendly functions include
maximum/minimum value display, low battery indication, LUX/FC unit, auto power off, data
hold and zero calibration.
FEATURES:
• Built–in high precision diode sensor and color correction filter for indoor use
• Both digits and analog bargraph display
• User–friendly functions: max./min. value display, low battery indication, LUX/FC unit,
auto power off, data hold, zero calibration
• Range: 20, 200, 2000, 20000, 200000 LUX, 20, 200, 2000, 20000 FC
• Ring Spectral Range: 320‑730 mm
• Accuracy: ±3% (calibrated to standard incandescent lamp and LED at 2,854K) ±6%
(calibrated at other visible light source)
• Applications: for all visible light and LED white, (red), (yellow), green, (blue), purple color
• Unit Selection: LUX.FC (Foot candles)
• Sensor: Silicone photodiode
• Sampling Time: ≥2 times/sec.
• Auto Power Off: after 10 min. after no use
• Operation Sound: Selection
• Low Battery Indication: <7V
• Operation Environment: 0‑85%RH, 10‑50°C (no condense)
• Power: 9V battery (not included)
• Dimensions: 6.7" x 3.2" x 1.8"

NT-309
Smart Non–contact Voltage Tester

DESCRIPTION: Non‑contact voltage tester detects AC voltage from
12 to 1000 VAC without metallic contact. Portable device ideal for
electricians, maintenance staff, service and safety personnel, and
even homeowners.

FEATURES:
• CAT III 1000V Safety rating
• Detects AC voltage from 12 to 1000 VAC without metallic contact
• Compact size with pocket clip easily fits into pockets or tool
pouches
• Voltage level indication, red LED and audible alarm if voltage is
present
• Entire outer surface is non‑conductive for safety, helps avoid high
voltage shock
• Built‑in white LED illumination light provides convenient work in
dark areas
• Powered by 1.5V AAA x 2 batteries (not included)
• Ideal for electricians, maintenance staff, service and safety
personnel, and even homeowners
