Hole Making

902-481 QuikPunch Kit
HOLE MARKING • Application: Punch mild steel up to 10 gauge, aluminum, fiberglass and plastic.
• Description: 6pc manual knock out set.
• Packaging: Blow-molded Case.
• 1/2'' to 2'' conduit sizes.Punched holes are actually larger.

Slug is split in half as punching
operation is completed.
Replacement
902-485 Replacement Punch Die Set - 1/2'' Type C
902-486 Replacement Punch Die Set - 3/4'' Type C
902-487 Replacement Punch Die Set - 1'' Type C
902-488 Replacement Punch Die Set - 1-1/4'' Type C
902-489 Replacement Punch Die Set - 1-1/2'' Type C
Punch design creases slug as the 902-490 Replacement Punch Die Set - 2'' Type C
punch is drawn into die.
Split slugs fall free from die and stud. 902-481-SBS Replacement Shaft and Bearing - Small
902-481-SBM Replacement Shaft and Bearing - Medium
500-036 Hole Saw Kit
• 11pcs hole saw
• Long lasting bi-metal material
• Very sharp,cut through material fast
• Cut through wood,plaster,mild steel
• 3 different sized arbors
• Triangular shank 1/4” fits hole saws 7/8”,1-1/8”
• Triangular shank 7/16” fits hole saws 1-3/8” 1-1/2”, 1-3/4”,
2”,2 1/2”, 3”, 3-5/8”, 4-1/8”, 4-1/2”
• SDS plus shank fits hole saws 7/8”, 1-1/8”
• Extension Bar: 12” length fits hex shank 7/16” arbor
• Hex Key: 4mm
Contents
11pcs hole saw : 7/8”, 1-1/8”, 1-3/8” 1-1/2”, 1-3/4”, 2”, 2-1/2”, 3”, 3-5/8”, 4-1/8”, 4-1/2
12” extension arbor
1/4" arbor,7/16" arbor
SDS plus arbor
Sturdy blow-molded case
Individual packing Color Label
902-482 Tuff Punch
• Description: Hydraulic Knockout Punch with Type C punch/die sets
• Application: Lightweight design for fast, easy one-person operation.
Develops 6.75 Tons of hydraulic force for easy punching.
• Packaging: Blow-molded Case

Included in kit:
Round knockout punches type c ½”, ¾”, 1”, 1-1/4”, 1-1/2”, 2”
7/16"X3/4" draw stud 1 Pc
3/4"X3/4" draw stud 1 Pc
Spacer 1 Pc
Blow-molded case 1 Pc
