Insertion and Removal Tool Selection Charts Listed by Contact Manufacturer

TOOL IDENTIFICATION NUMBERS I/R R/F USAGE/ ILL. GAGE CONNECTOR
DESCRIPTION SERIES
ITT/CANNON ASTRO TOOL #
CeT P-CTA ATC 2035 R F Centi Lok 2dd Pins 1 22 dd
CeT S-CTA ATC 2036 R F Centi Lok 2dd Sockets 1 22 dd
CeT TF ATC 2026 R F Tuning Fork Contacts 11 -- IdenTIFICATIOn InFORMATIOn
CeT Ve-0 ATC 2565 R R MIL-C-5015, Rear Release 19 0
CeT Ve-4 ATC 2426 R R MIL-C-5015, Rear Release 19 4
CeT Ve-8 ATC 2281 R R MIL-C-5015, Rear Release 19 8
CeT Ve-12 ATC 2184 R R MIL-C-5015, Rear Release 10 12
CeT Ve-16 ATC 2136 R R MIL-C-5015, Rear Release 10 16
CIeT 12 ATR 1160 I R Metal Tool, nAS 1664 for nAS 1599 2 12 kV/PV/dPk
ATR 2160 R R Metal Tool, nAS 1664 for nAS 1599 10 12 kV/dPk/PV
CIeT 16 ATR 1107 I R Metal Tool, nAS 1664 for nAS 1599 2 16 dPXMe
ATR 2112 R R Metal Tool, nAS 1664 for nAS 1599 10 16 dPXMe
CIeT 20 ATR 1080 I R Metal Tool, nAS 1664 for nAS 1599 2 20 dPXMe
ATR 2080 R R Metal Tool, nAS 1664 for nAS 1599 10 20 dPXMe
CIeT 20-18 ATC 1081 I R Metal Tool, Joggled 2 20 d*C
ATC 2076 R R Metal Tool, Tweezer 10 20 d*C
CIeT 20Hd ATC 1076 I R Metal Tool, Tweezer 10 20 d*RA
ATC 2076 R R Metal Tool, Tweezer 10 20 d*RA
CIeT 20HdL ATC 2076-L R R Metal Tool, Tweezer, Long Tip 10 20 dPXMe
CIeT Ck-1 ATC 3050 R R Metal Tool 3 22 dPX
CIeT 22 ATC 1054 I R Metal Tool, Joggled 2 22 dPX2MA
ATC 2053 R R Metal Tool, Tweezer (ref. ATC 2054) 10 22 CenTI-k
ATC 2053-70 R R Modified version of ATC 2053 (70 degree angle) 10 22
ATC 1054-S I R Modified version of ATC 1054 (straight) 1 22
CIT 4 ATC 1377 I R Metal Tool, Straight 1 4 RX
CIT 8 ATC 1265 I R Metal Tool, Straight 1 8 RX
CIT 12 ATC 1160 I R dP*M, dPS, MS-e, kMBA Connector 2 12 RX
CIT 12-1 ATC 1160 I R RX Contacts 2 12 RX
CIT 12-2 ATC 1160 I R RX Contacts 2 12 RX
CIT 16 ATC 1111 I R Ring-Lok dP*M, kMB, SRC 2 16 RX
CIT 16-1 ATC 1111 I R Ring-Lok dP*M, kMB, SRC 2 16 RX
CIT 16-2 ATC 1111-1 I R Ring-Lok dP*M, kMB, SRC, Long Tip 2 16 RX
CIT 16-9 ATC 1112 I R Ring-Lok dP*M, kMB, SRC 2 16 RX
CIT 16kJ ATBX 1108 I R MIL-C-38999 10 16 kJ
CIT 20 ATA 1086 I R dP*M, kQ, kR, kTM, MIL-C-26636, Metal Interchangeable Probe 26 20 SRC
Tool
CIT 20-2 ATC 1079 I R dSM 2 20 BFRX
CIT 20-5A ATC 1084 I R kPTM 2 20 kPTM
CIT 20-18 ATC 1081 I R 038894-0018 2 20 kPTM
CIT 20A ATC 1055 I R ddSMI 2 20 d
CIT 20d ATC 1072 I R dPXMe-20 H.d. 2 20 d
