接上页

不防水, 有预置功能, 带数据接口(读数无需加测爪宽度) (mm)
型号 测量范围 类型 精度 L a b c d e f 数据传输
1120-150A 22-150mm/0.87-6" A ±0.04mm 250 5 11 16 30 1 4
1120-1501 35-150mm/1.38-6" A ±0.06mm 250 6 17.5 16 60 1.5 4 2
数据线
1120-200A 25-200mm/0.98-8" A ±0.04mm 310 5 12.5 16 40 1 4
(型号7315-21需选配接收器页码9,
1120-2001 40-200mm/1.57-8" A ±0.06mm 310 7 20 16 70 2.5 4 7302-21页码23, 选配)
1120-300A 30-300mm/1.18-12" A ±0.05mm 410 5 15 16 50 1.5 4
1120-3001 50-300mm/1.97-12" A ±0.07mm 410 8 25 16 80 2.5 4
1120-500 40-500mm/1.57-20" A ±0.07mm 680 5 20 24 90 2.2 5.5
数据线
1120-5001 60-500mm/2.36-20" A ±0.08mm 680 10 30 24 120 3.4 5.5 (型号7315-22需选配接收器页码9,
7302-22页码23, 选配)
1120-5002 80-500mm/3.15-20" A ±0.08mm 680 16 40 24 150 5.2 5.5

不防水, 有预置功能, 内置无线(读数无需加测爪宽度, 需选配接收器, 型号7315-2/3/6/7/8/9)
型号 测量范围 类型 精度 L a b c d e f
1120-150AWL 22-150mm/0.87-6" A ±0.04mm 250mm 5mm 11mm 16mm 30mm 1mm 4mm
1120-1501WL 35-150mm/1.38-6" A ±0.06mm 250mm 6mm 17.5mm 16mm 60mm 1.5mm 4mm
1120-200AWL 25-200mm/0.98-8" A ±0.04mm 310mm 5mm 12.5mm 16mm 40mm 1mm 4mm
1120-2001WL 40-200mm/1.57-8" A ±0.06mm 310mm 7mm 20mm 16mm 70mm 2.5mm 4mm
1120-300AWL 30-300mm/1.18-12" A ±0.05mm 410mm 5mm 15mm 16mm 50mm 1.5mm 4mm
1120-3001WL 50-300mm/1.97-12" A ±0.07mm 410mm 8mm 25mm 16mm 80mm 2.5mm 4mm
1120-500WL 40-500mm/1.57-20" A ±0.07mm 680mm 5mm 20mm 24mm 90mm 2.2mm 5.5mm
1120-5001WL 60-500mm/2.36-20" A ±0.08mm 680mm 10mm 30mm 24mm 120mm 3.4mm 5.5mm
1120-5002WL 80-500mm/3.15-20" A ±0.08mm 680mm 16mm 40mm 24mm 150mm 5.2mm 5.5mm

IP67防尘/防水, 无数据传输, 不自动关机, 每次开机需置零, 无预置功能(读数需加测爪宽度)
型号 测量范围 类型 精度 L a b c d e f
1120-150P 22-150mm/0.87-6" C ±0.04mm 250mm 5mm 11mm 16mm 30mm 1mm 4mm

扁头内沟槽游标卡尺

1262-150A
单位: mm
236
符合JB/T异形卡尺国家机械行业标准
用于测量孔内沟槽 16
不锈钢尺身
刻度面镀暗铬
35 4
20
型号 测量范围 分度值 精度 2 9
4
1262-150A 18-150mm 0.02mm ±0.04mm

78
