We Make Connections EZ! Kits

Cat6A/7 28-26 AWG Termination Kit
This shielded Cat6A/7 RJ45 (8P8C) modular connector is designed to terminate round solid or
stranded, 28 – 26 AWG, Cat6A/7 network cable. The connector contains 3-Prong contacts that
hold the wire in place giving a reliable connection. This connector meets and exceeds 10Gig
performance standard.

90180
Kit Includes: Application: • Over-sized Cat5e/6
• Cat6E
• Tele-TitanXg 2.0 Crimp Tool • CCS-6 Cable Cutter • Cat6A Industrial Ethernet Cables
™
• Cyclops 2 Cable Jacket Stripper • RJ45 Cat6A/7, Shielded • Cat7
• 5" Side Cutting Pliers Connectors (100)
Connector
Part # Description Liner
90180 Cat6A/7 28-26 AWG Termination Kit Space bar

106240

RJ45 Cat6A/7 28-26 AWG 10Gig
Shielded Connector:
• Cable Jacket OD Range:
0.224" – 0.335" (5.7mm – 8.5mm)
• Insulation Diameter Range:
0.037” – 0.041" (0.94mm – 1.05mm)
• Meets 10Gig performance standard
• Round Solid or Stranded, 28-26 AWG
• Meets ANSI/EIA/TIA/TAA specifications
• UL, FCC and RoHS compliant

Cyclops 2 Cable Jacket Stripper
• Self-adjusts to automatically
score PVC and Plenum
• Ready-to-use out of the kit
• Works with shielded/unshielded
twisted pair and fiber optic cables
• Accepts cable ODs
Tele-TitanXg 2.0 Crimp Tool 0.10" to 0.43"
• Specifically made for terminating External Ground Crimp (2.5mm – 11mm)
Platinum’s RJ45 Cat6A 10Gig
Shielded Connectors, Cat6E, Cat6A, 15010C
Cat7, and over-sized Cat5e/6
Industrial Ethernet Cables 5" Side Cutting Pliers CCS-6 Cable Cutters
(Not for standard RJ45 modular plugs) • Cuts copper wire and soft • Cuts RG11/7, RG59,
• Straight action crimp achieved 12516C metals up to 16 AWG RG6, RG6Q with steel
with minimal hand force • 21° full flush cut center conductor
• Crimps external grounds RJ12/11 w/spring action • Heat-treated, precision
ground blades
10Gig RJ45
10531C

10514C
