Connectors

Cat6A/7 28-26AWG Connectors

This shielded Cat6A/7 RJ45 (8P8C) modular connector is designed to terminate round RJ45 Cat6A/7 28-26AWG
solid or stranded, 28 – 26 AWG, Cat6A/7 network cable. The connector contains 3-Prong
contacts that hold the wire in place giving a reliable connection. This connector meets and STP, Solid/Stranded
exceeds 10Gig performance standard.
Packaging Description Item
Features Bag – 100 Pieces 106240
• Cable OD range: 0.224" – 0.335" (5.7mm – 8.5mm) Bag – 25 Pieces 106241
• Insulation diameter range: 0.037" – 0.041" (0.94mm – 1.05mm) Bag – 50 Pieces 106242
• Designed for both shielded and non-shielded cables Clamshell – 10 Pieces 106243C
• Compatible with CAT7, CAT6A, CAT6E, and CAT6
• Meets ANSI/EIA/TIA/TAA specifications Spare Liners
• Round Solid and Stranded, 28–26 AWG
• Shielded Connector, External Ground Bag – 50 Pieces 106244
• 3-Prong, 50 micron Gold plated Contacts Spare Spacer Bars
• 3 Piece with Liner and Spacer Bar
• Meets 10Gig Performance Standard Bag – 50 Pieces 106245
• UL and RoHS/FCC compliant
• Color: Clear/Transparent

See page 20 for Tele-Titan Xg 2.0
TM
CAT6A/10Gig Crimp Tool
See page 91 for 10Gig Termination Kit
Copper Foil Strips

Platinum Tools Copper Foil Strips consist of a copper foil backing and conductive adhesive.
The Copper Foil Strips are supplied on removable paper sheet for easy handling. Copper foil
strips are typically used as an EMI / RFI shielding for applications in the electronics industry Copper Foil Strips
such as static charge draining, seaming shielded rooms, cable wrapping, and surface Packaging Description Item
contact to non-solderable materials. These copper foil strips work perfectly with all the
Platinum Tools Shielded RJ45 Connector and Shielded Keystone Jacks. Pack – 100 Pieces 2039

Features
• Conductive Adhesive Copper Foil Application
• EMI/RFI Shielding Strips Instructions
• Improves Bandwidth Performance See Page 107
• 10 strips per sheet (10 sheets per pack) 100 pcs

Copper Foil
