We Make Connections EZ! Connectors

Standard Modular Plugs

Cat6
RJ45 – 8P8C
Two Piece Design: 50μ
Shielded
Non-Shielded
Round, Solid, Non-Shielded Round, Solid, Shielded RJ45 - High Performance
Packaging Description 3 prong conductor contact, w/Liner 3 prong conductor contact, w/Liner
Clamshell – 25 Pieces 106187C Clamshell – 10 Pieces 106208C
Jar – 100 Pieces 106188J Clamshell – 50 Pieces 106207C
Bag – 500 Pieces 106185 Jar – 100 Pieces 106206J
Spare Liners Tray – 100 Pieces 106205

Clamshell – 50 Pieces 106189
Liner is for shielded and non-shielded
Max cable OD: 0.285" or 7.24mm I Max conductor OD: 0.044" or 1.12mm I 23-24 AWG

Cat6 Three Piece Design: 50μ
RJ45 – 8P8C
Round, Stranded Round, Solid
Packaging Description 2 prong conductor contact 3 prong conductor contact
Clamshell – 25 Pieces 106172C 106177C
Jar – 100 Pieces 106173J 106178J
Bag – 500 Pieces 106170 106175
Max cable OD: 0.270" or 6.85mm I Max conductor OD: 0.040" or 1.01mm I 24 AWG

RJ45 Cat6A 10Gig Shielded Connectors with Liners

Platinum’s 10Gig System was developed to support today’s 10Gig infrastructure. In environments where speed transmission, uptime, and
response are critical, companies are using 10Gig. It delivers the necessary bandwidth and also builds for future emerging technologies.
Our system addresses the challenges of working with larger cables like Cat6E, Cat6A, and Cat7. Our connectors deliver the performance
needed to stream large data, audio, and video files. Coupled with the
Tele-TitanXg or the Tele-TitanXg 2.0, you can rest assured your installation RJ45 Cat6A
exceeds industry standard performance.
10Gig Connectors
Features
• Exceeds 10Gig performance standard Packaging Description Solid Stranded
• UL and RoHS compliant Clamshell – 10 Pieces 106193C 106198C
• Max cable OD: 0.335" (8.5mm) Clamshell – 50 Pieces 106192C 106197C
• Insulation diameter: 0.043" – 0.053" (1.09mm – 1.35mm) Bag – 25 Pieces 106191
• Designed for shielded & non-shielded cables
Bag – 50 Pieces 106192 106197
Bag – 100 Pieces 106190BG
Connector
Bulk – 100 Pieces 106190 106195
Liner
See page 90 for 10Gig Termination Kit
See page 20 for Tele-Titan Xg 2.0 Spare Liners
TM
CAT6A/10Gig Crimp Tool Bag – 50 Pieces 106194
P/N 106190
