KL-1010-90 K
静音轴承拆装工具组套 NEW
SILENT BLOCK TOOL KIT
适用于拆装各种商用车开式和闭式静音轴承。
Universally suitable for slotted and closed silent blocks
on commercial vehicles.
• 适用外径 ( 安装状态 / 拆卸后膨胀状态
• For outside diameters (installed/removed) 51/52, 60/62, )
51/52, 60/62, 63/65, 65/70, 75/80 mm
63/65, 65/70, 75/80 mm
• 可以在车辆上直接进行快捷且符合规范地拆
• Enables the quick and professional removal and
NEW • 需要另外匹配机械驱动顶杆套装
除和安装
installation directly on the vehicle
• Additional mechanical drive pcs necessary! !
Suitability: Universal, particularly for
适用范围 : 通用型、特别适合
MERCEDES RENAULT VOLVO MAN

编号 编码 Bearing diameter (installed) 宽 ( 外壳 Depth (case) ) Height (case) )
Code
深 ( 外壳
轴承直径 ( 安装状态）
高 ( 外壳
No.
Width (case) )
3425703 KL-1010-90 K 51 / 60 / 63 / 65 / 75 mm 442 mm 357 mm 151 mm
KL-1010-106 K
驱动套组 28T 适用于 KL-1010-SERIES 系列
DRIVE KIT 28T FOR KL-1010-SERIES
驱动套组适用于商用车工具组套 KL-1010-90-K
Appropriate drive pcs for the commercial vehicle tool
kit KL-1010-90-K.
包含 :
Consisting of:
• Hydraulic cylinder 28t
• 液压缸 28t
• Pulling spindle M20 x 590 mm
• 拉杆 M20 x 590 mm
• Quick-release nut M20
• 速紧螺母 M20
• Adapter
NEW • 适配器 KL-4999-420
• Support sleeves, long, Ø 70 / 90 mm
• 支撑套筒 , long 长型 , Ø 70 / 90 mm
• Support sleeves, short, Ø 70 / 90 mm
• 支撑套筒 , short 短型 , Ø 70 / 90 mm
Hydraulic pump required!
需要液压泵

编号 编码 Max. load on the hydraulic cylinder Max. load of pull spindle 宽 ( 外壳 深 ( 外壳 高 ( 外壳
拉杆最大负载
液压泵最大负载
No.
Code
Width (case) )
Height (case) )
Depth (case) )
3427846 KL-1010-106 K 28 t 20 t 442 mm 357 mm 151 mm
KL-1011-121
静音轴承工具
BPW SILENT BLOCK TOOL
用于孔径 为 132 mm 的静音轴承。
Suitable for silent blocks with an axle bore diameter of 132 mm.
Time saving, safe, well thought out tools.
Time saving, safe, well thought out tools.
• 适用于快速且符合规范地压入和拆
• For quick and professional insertion and
除支承接头
removal on the wishbone
NOVELTIES • 例如，用于空气悬架 302 pcs KL-4999-420 1000kg / 750kg
NOVELTIES
• 适用于钢橡胶复合轴套
• For steel-rubber bushings No. 02.0314.38.00
No. 02.0314.38.00
• For example, on BPW ECO Air/ECO Air
Compact axles
• Additional mechanical drive pcs necessary!
BPW ECO Air/ECO Air Compact
• 需要另外匹配机械驱动顶杆套装
Suitability: Universally
适用范围 : 通用型
3418367
2022
2022 编号 NEW Sleeve Thrust piece bore Weight
编码
套筒
重量
Code
No.
6.8 kg
锥形
3417158
KL-1011-121
