General workshop equipment General workshop equipment

Tool trolley / Work bench accessories Tool trolley / Work bench accessories

Tool trolley accessories Tool trolley accessories
C C
1) Observe application note
1 4 1 4

• Vertical tool panel
• Attachable to i 179N ∙ 179NX tool trolleys
• Holds additional tools
• Assortment of holders included 112-260 ∙ 112-325 ∙ 112-350 ∙
112-450 ∙ 112-612 ∙ 112-618 ∙ 112-624 ∙ 112-830
179 N-26 215522
• Tray holder
• For tool trolleys i 177 ∙ 178N ∙
179N ∙ 179NX ∙ 179NXL ∙ 179NXXL ∙ 179NXXL-8D
and work bench i 177W
• Secure tensioning mechanism works for all standard
tablet/PC models between 120 and 222 mm
• Universally suitable for Apple iPad ∙ mini ∙ Air ∙ Pro,
Amazon Kindle ∙ Fire, Samsung Galaxy Tab, Google
Nexus, Asus Transformer, Microsoft Surface
Use of tablets with protective cover or case is possible
• Clamp draw spring enables quick insertion and removal
• General clamping jaws with integrated foam rubber pad
guarantee secure hold without damaging the device • Vertical tool panel
• Adjustable bracket with felt pad and rubber cap for • Can be screwed onto workbench i 179NW
additional security when the tablet holder is positioned • Holds additional tools
vertically – Prevents the tool from falling out • Assortment of 8 holders included:
• Individually adjustable clamping jaws – the 112-260 ∙ 325 ∙ 350 ∙ 450 ∙ 612 ∙ 618 ∙ 624 ∙ 830
operating controls on the device are • Number of perforations: 336
in no way functionally impaired • L 1150 x W 10 x H 510 mm
• Quick switch between profile and landscape 179 N W-26 219612
formats, undesired turning is not possible
• Mounting on round pipes (maximum 30 mm) and
worktops possible
The bracket is fixed using a clamping screw
179 N-45 1) 224210

• Vertical tool panel
• Attachable to i 179NXL tool trolleys
• Supplementary storage drawer, for right storage compartment • Holds additional tools
• For work bench i 179NW • Assortment of holders included 112-260 ∙ 112-325 ∙ 112-350 ∙
• Dimensions (inner) W 318 x D 398 x H 77 mm 112-450 ∙ 112-612 ∙ 112-618 ∙ 112-624 ∙ 112-830
• 25 kg loading capacity with self-retraction 179 N XL-26 215539
179 N W-22 219636

• Tray • Vertical tool panel
• For work bench i 179NW • Attachable to tool trolleys i 179NXXL ∙ 179NXXL-8D
• Flexible installation into the right storage compartment • Holds additional tools
• Loading capacity 15 kg • Assortment of holders included 112-260 ∙ 112-325 ∙ 112-350 ∙
• Including 4 screws 112-450 ∙ 112-612 ∙ 112-618 ∙ 112-624 ∙ 112-830
179 N W-23 220199 179 N XXL-26 215546
B B
56 Errors excepted Components and spare parts from page 500 to 509
