Specialty tools

Engine – Cooling system / Hose connection

4797 Injector extractor 4797 Injector extractor

Made in Germany ß C ß
• Application: For disassembly of tight common rail
injectors without removing the cylinder head
1 K è 4
• Piezo injector claw G
• Removal of Piezo injectors on MERCEDES-BENZ engines OM 651
• The design of the injector claw, tuned to the injector, ensures
optimal reception of the injector during operation
• MERCEDES-BENZ:
A-class type 176 ∙ B-class type 246 ∙ C-class type 204, 205
E-class type 212 ∙ S-class type 221, 222 ∙ V-class type 639, 447
CLA type 117 ∙ GLA type X156 ∙ GLK type X204
CLS type 218 ∙ ML type 166 ∙ SLK/SLC type 172 ∙ GLC type X253
• Operation with the HAZET impact extractor 4797-1
• Inside thread: M16 x 1.5 mm
4797-9 54.5 – 206667 F

Thread repair tool set for
4797
injector fastening screw
YouTube Clip
4797-1
• For MERCEDES-BENZ CDI engines. Suitable for ß/
reaming the broken-off expansion bolt M6 x 1 from the
cylinder head without removing the valve cover
• Enormous money and time saving as the replacement of cylinder head D
and the removing of injectors and valve covers is not necessary
• Damaged thread is reworked to M8 x 1
Contents:
1 twist drill 6 mm with spacer sleeve
4797-2 4797-3 4797-9 1 tap M8 x 1
1 drill sleeve
1 twist drill 7 mm with spacer sleeve and guide tube
1 knob for screwing
1 K è 4 5 threaded inserts M6 x 1 YouTube Clip
• Plastic box 165-S (1/9)
• For e.g. MERCEDES-BENZ CDI engines 611 ∙ 612 ∙ 613 etc. • Safety-Insert-System, 2-component soft foam insert. R
• Especially suitable for the limited spaces due to the cylinder head cover Insert also suitable for HAZET Assistent
4797/2 460 2 121205
• Impact extractor
• M16 x 1.5
• Striking weight: 1.8 kg
4797-1 460 – 121175
• Injector claw
• M16 x 1.5
4797-2 130 – 121182 C
• External adapter with inside thread M16 x 1.5 on M27 x 1
• Removal of Bosch injectors with outside thread M27 x 1
• In conjunction with impact extractor 4797-1
• Operating mode: 1 L x W x H è 4
The external adapter must be used when the injector claw cannot be used, mm
either because of the vehicle type or because of the lack of space. 4797/10 185 x 153 x 52 10 191505
Note: after removing the injector with the external adapter, replace the injector
4797-3 50 – 121199 • Threaded inserts ∙ 5 pieces M6 x 1 for 4797/10
B 4797-M 6 x 1/5 – 5 192441
O
Cooling system / Hose connection

798 Hose clamp pliers 798 Hose clamp pliers

Made in Germany G/ Made in Germany G/
• Application: Simple hose clamps, e.g. on washing machines • Locking device, adjustable jaw opening
• Rotating jaws – for areas with restricted access
• Surface: chrome-plated • Application: Simple hose clamps A
• Rotating jaws – for areas with restricted access
• Surface: chrome-plated

U

1 K U 4 1 K U 4
798 206 40 031832 798-1 285 45 031900
