Workshop tools · Safety at work Workshop tools · Safety at work

Lubrication technology Lubrication technology

2162 High performance suction gun 2162 Hand-operated dosing pump

• Unneeded material can be easily sucked out • Double scaling for precise metering
• Flexible plastic hose outlet
• Housing material: galvanised steel • Suitable for:
Biological oil ∙ Drilling oil ∙ Diesel oil ∙ Antifreeze ∙ Heating oil ∙ Hydraulic oil ∙
Coolant ∙ Cooling lubricant ∙ Multifunctional oil ∙ Petroleum ∙ Cutting oil ∙ Synthetic
oil ∙ Contaminated waste oil ∙ Water ∙ Water emulsion
Not suitable for explosive liquids such as petrol
• Coupler thread (hose/pipe) on the pump bottom: M15 x 1.5
• Housing material: PVC (transparent)
• Hose inside x: 10 mm
• Hose outside x: 16 mm
• NBR seals
• Unneeded material can be easily sucked out
• Incl. flexible, transparent plastic hose fibre-reinforced
• Including curved 120° aluminium application tube x 10 mm
• Absorbent and smooth
• Hose length: 600 mm plus application tube
2162-6 • Maximum transport volume 4 l/min
• Length without house: 545 mm

1 ] 4
• Filling capacity: 500 ml
• Inside diameter of the hose: 9.5 mm
• Outside diameter of the hose: 12.5 mm
• NBR seals
• For engine oils with a viscosity of 30 to 68
• Not suitable for acidic (erosive) liquids
2162-4 0.5 174850 1 ]
• Metal outlet also included 4
• Filling capacity: 1000 ml 2162-8 1 213337
• Inside diameter of the hose: 9.5 mm
• Outside diameter of the hose: 12.5 mm
• NBR seals 2163 Hand pump ∙ with telescopic suction tub
• For engine oils with a viscosity of 30 to 68
• Not suitable for acidic (erosive) liquids Made in Germany
1
• Coupler thread (hose/pipe) on the pump bottom: 12.7 mm ( ⁄4″) PT x 19 • For drums from 50 to 200 l
2162-6 1 174454 • Telescopic suction tube made of metal,
extendable from 450 to 860 mm
• Base component made of galvanised steel
2162 Manual decanting / filling pump • R 2“ and R 1. ⁄2“ drum adapters
1
• Removable curved metal outlet
Made in Germany • Flow rate: approx. 0.35 litres / stroke or 16 l/min.
• 600 ml pump volume enables fast transfer pumping and filling of fluids • Weight: 2.2 kg
between different tanks Caution: Not suitable for gasoline extraction
• Application: Filling and decanting liquids
• Base plate and double connection for hoses with 10/15 mm inside x
• 1 suction hose,x 10 mm ∙ length: 3 m
• 1 pressure hose, x 15 mm ∙ length: 3 m
• On e.g. MERCEDES-BENZ Citaro Euro 6 together with coolant pipe
2 x A.311.500.09.91 and coupling muff A.001.553.19.26 and coupler
plug A.001.553.20.26
• Transmission or engine oils can
be filled quickly, bubble-free
and cleanly using the pump
• Fluids to be transferred, e.g.
– Ad Blue
– Coolant
– Windscreen frost protection
– Oil 1 4
– Water
2163-1 172771

1 4
2162-7 207756
404 Errors excepted Components and spare parts from page 500 to 509
