Hand tools Hand tools

Tools with protective insulation / Tools for electricians Tools with protective insulation / Tools for electricians

1863 Wire stripper ∙ automatic 2156 Cable knife

• Automatic adjustment to insulation thickness, easy application – K • Blade made of stainless steel K
perfect result • Plastic handle
• Application: Wire stripping of electrical conductors, stranded wires and cables
• For copper and aluminium conductors
• Stripping range PVC-insulated conductors, cross-section 0.2 up to 6 mm 2
• Maximum stripping length: 18 mm 1
• Spring-loaded K 4
knife-type blades 2156 110 013180
• Wire cutter for
2
4 mm single-wired
and 6 mm fine-wired Cable stripping knife ∙
2
2156 VDE
with protective insulation
Made in Germany B K
• With protection cap
• Blade made of
stainless steel
• Plastic handle
• IEC 60900:2018
1 K 4
1863 205 007325
1 K 4
4656 Crimping pliers 2156 VDE-2 180 173549
Made in Germany K
• Creation of conductor crimp and insulation crimp in one working step 2158 Universal shears
• Intensive insulation crimp with special profile geometry • Ergonomic design allows one-hand operation of the locking device A
• Integrated lock with releasing mechanism provides complete crimp
• All stressed parts are specially tempered • Blades: rust-resistant stainless steel
• Easy handling • Locking device
2
• Profile coding • Additionally with round cutter for wire stripping (1 or 1.5 mm )
• Profiles / cross-sectional areas: • Wire guide for cutting lashing wire up to 2.5 mm x
red: 0.5–1.0 mm / AWG 20–16 • HAZET 2-component handle
2
blue: 1.5–2.5 mm / AWG 16–14
2
yellow: 4.0–6.0 mm / AWG 12–10
2
• Ergonomic soft grip handles with anti-slip covers
• Surface: burnished, oiled

1 K 4
2158 194 057856

196 VDE Insulating mat
1 K 4
4656-1 220 127351 Made in Germany K
• For working on high-current parts

4658 Crimping pliers • Rubber mat, tested: 50,000 V, according to VDE 0303
• One side smooth and one side anti-slipping, grooved
Made in Germany K • Dimensions: 1000 x 1000 x 4.0 mm
• For a multitude of non-insulated cable and plug-type connectors
• Integrated lock with release mechanism ensures complete crimping process Carrier bag design
• Less expenditure of force due to an optimal force transmission ratio • Carrying strap removable
• Length: 1000 mm
• Linear crimping providing consistent rolling of conductor and insulator crimp • Diameter: 160 mm
• The insulation stop allows the positioning of the contact in the
crimping profile independent of the type of contact used • Polyester, red
• Change head for cross sections 0.35 –1.5 mm complete, including basic tool
2
• 1st profile: 0.35 – 0.5 mm
2
2
2nd profile: 1.5 mm
3rd profile: 0.5 – 1.0 mm
2
conductor crimp =
B-crimp / insulation
crimp = O-crimp

1 K 4 1 è 4
4658-10 150 129515 196 VDE-8/2 2 174836
