188/2 12p 188/2L6p 188.1/1ABI
Socket 1/4", 12 point Socket 1/4", long type, 6 point Reversible ratchet 1/4"

› material: premium &ex chrome vanadium steel › material: premium &ex chrome vanadium steel › material: premium &ex chrome vanadium steel

› drop forged, entirely hardened and tempered › drop forged, entirely hardened and tempered › body drop forged

› surface "nish: chrome plated according to ISO › surface "nish: chrome plated according to ISO › entirely hardened and tempered

1456:2009 1456:2009 › surface "nish: chrome plated to standard ISO
› made according to standard ISO 2725-1 (only › made according to standard ISO 2725-1 (only 1456:2009
metric dimension) metric dimension) › ergonomic heavy duty double component
handle
› made according to standard ISO 3315
Advantages:
› with 40 - teeth
› 9° working angle
› Safety lock system
SKU L D1 D2 T
› The socket is be released from the ratchet by
618697 3.2 50 6 12 8 20
simple pressing the button.
616881 4 50 6.8 11.9 5 20
616882 4.5 50 7.1 11.9 5 20
SKU L D1 D2 T
616883 5 50 8 11.9 5 20
616857 4 25 6.8 11.9 5 15
616884 5.5 50 8.3 11.9 5 20
616858 4.5 25 7.1 11.9 5 15
616885 6 50 9.3 11.9 8 20
616859 5 25 8 11.9 5 15 616886 7 50 10.5 11.9 8 31
616860 5.5 25 8.3 11.9 5 15 616887 8 50 11,9 11.9 8 71
616861 6 25 9.3 11.9 5 15 616888 9 50 13,1 13.1 11 71
616862 7 25 10.5 11.9 5 15 616889 10 50 14,5 14.5 11 71
616863 8 25 10.5 11.9 5 15 SKU L A B
616890 11 50 15,8 15.8 11 71
616864 9 25 10.5 13.1 8 15 611901 1/4" 157 24.5 25 111
616891 12 50 16,8 16.8 13 71
616865 10 25 10.5 14.5 8 39
616892 13 50 17,8 17.8 13 71
616866 11 25 10.5 15.8 8 39 616893 14 50 19,6 19.6 16 71
616867 12 25 10.5 16.8 8 39
616868 13 25 10.5 17.8 10 39
616869 14 25 10.5 19.6 10 39 189/2
616870 3/16" 25 8 11.9 5 15 Socket with internal TX pro!le 1/4"

616871 7/32" 25 8.3 11.9 5 15
616872 1/4" 25 9.3 11.9 5 15
616873 9/32" 25 10.5 11.9 5 15
616874 5/16" 25 10.5 11.9 5 15
616875 11/32" 25 10.5 12.9 5 15
616876 3/8" 25 10.5 13.9 8 39
616877 13/32" 25 10.5 14 8 39
616878 7/16" 25 10.5 15.8 8 39
616879 1/2" 25 10.5 17.8 10 39
616880 9/16" 25 10.5 19.6 10 39

› material: premium &ex chrome vanadium steel
› drop forged, entirely hardened and tempered
› surface "nish: chrome plated according to ISO

1456:2009

SKU L D2 D1
607911 E 4 25 12 5.4 15
607912 E 5 25 12 6.7 15
607913 E 6 25 12 7.7 15
607914 E 7 25 12 8.3 15
607915 E 8 25 12 10.1 15
607916 E 10 25 12 11.3 15
607917 E 11 25 12 12.9 15

1/4" DRIVE SOCKETS AND ACCESSORIES 53
