P. 34
180/1 180/1CB 180/1CB
O#set ring wrench Set of o#set ring wrenches in carton Set of o#set ring wrenches in carton
box box
› material: premium chrome vanadium steel Set includes: Set includes:
› drop forged, entirely hardened and tempered › 8x ring wrench (article 180/1) dim. 6x7, 8x9, › 13x ring wrench (article 180/1) dim. 6x7, 8x9,
› surface "nish: chrome plated according to ISO 10x11, 12x13, 14x15, 16x17, 18x19, 20x22 10x11, 12x13, 14x15, 16x17, 18x19, 20x22,
1456:2009 21x23, 24x26, 25x28, 27x32, 36x41
› polished head
› ring part with LIFE pro"le
› made according to standard ISO 10104 (only
metric dimension) SKU SKU
› made according to standard DIN 838 600541 6 - 22 8 600543 6 - 41 13
180/1CB 180/1CS
Set of o#set ring wrenches in carton Set of o#set ring wrenches in carton
box box
SKU L B1 B2 A1 A2
600511 6 x 7 178 10.3 11.8 5.5 6.1 48
600512 8 x 9 190 14 15,5 6.7 7.3 60
600513 8 x 10 166 12,9 15,5 6 8 50
602663 9 x 11 205 15,5 18,5 7,3 8,4 65
600514 10 x 11 205 17 18,5 7.9 8.4 81
602997 10 x 12 210 17 20 7.9 9 86 Set includes: Set includes:
600516 12 x 13 220 20 21,5 9 9.5 108 › 10x ring wrench (article 180/1) dim. 6x7, 8x9, › 8x ring wrench (article 180/1) dim. 6x7, 8x9,
600517 12 x 14 205 17.7 20.3 9 10 95 10x11, 12x13, 14x15, 16x17, 18x19, 20x22, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22
21x23, 24x27
600518 13 x 15 235 21,5 24 9.5 10.5 144
600519 13 x 17 258 21,5 27 9.5 11.5 172
600520 14 x 15 235 23 24 10 10.5 140
600521 14 x 17 257 19,8 23,6 10 12 173 SKU SKU
600522 16 x 17 258 26 27 11 11.4 187 603674 6 - 27 10 602845 6 - 22 8
603123 16 x 18 259 22,9 25,4 11 12 205
600523 17 x 19 270 27 30 11.4 12.4 233 180/1CB 180/1MS
600524 18 x 19 270 29 30 11.9 12.4 230
600525 19 x 22 295 30 35 12.4 13.7 308 Set of o#set ring wrenches in carton Set of o#set ring wrenches on metal
box stand
600526 20 x 22 295 32 35 12.8 13.7 320
600527 21 x 23 305 33 37 13.3 14,1 336
600528 22 x 24 315 35 38 13.7 14,6 368
600529 24 x 26 325 38 41 14.6 15,4 459
600530 24 x 27 325 38 42 14.6 15,8 453
600531 25 x 28 335 40 44 15 16,2 522
600532 27 x 29 335 42 45 15.8 16,6 589
600533 27 x 30 360 38,5 42,7 15 16 647
600534 27 x 32 360 42 49 15.8 17,8 672
600535 30 x 32 370 46 49 17 17,8 680
603124 30 x 36 395 43 48 15 18 845
600536 32 x 36 410 48.2 54.2 17.8 19.4 915
600537 36 x 41 450 48 56 19 21 945
602664 41 x 46 472 56 61 21 23 1430 Set includes: Set includes:
› 12x ring wrench (article 180/1) dim. 6x7, 8x9, › 12x ring wrench (article 180/1) dim. 6x7, 8x9,
10x11, 12x13, 14x15, 16x17, 18x19, 20x22, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22,
21x23, 24x26, 25x28, 27x32 21x23, 24x26, 25x28, 27x32
SKU SKU
600542 6 - 32 12 605545 6 - 32 12
32 WRENCHES
