2203/2BI 2206
Tool for rotating camshaft pulley Universal clutch aligner

› material: premium chrome vanadium steel › designed for most vehicles, with single plate
› material: pin from premium plus carbon steel clutches
› for holding pulleys on camshafts, injection › for clutch up to: 15 - 28 mm
pumps › Easy to use
› for timing pulleys, span from 24 to 160 mm › The tool under art. No. 2206 is the only universal
› available pin dimensions: Ø5.7, Ø7.7, Ø9.7, clutch aligner that allows you to align almost
Ø11.7, Ø18 any standard passenger car clutch. This is done
› heavy duty double - component handles directly between the clutch plate and the
pressure plate by using the universal clutch
› jet stamp UNIOR aligner to join them together. After the clutch
› Used to hold the camshaft pulley in place so aligner is removed, both parts of the clutch are
that the centre screw can be unscrewed prior to joined together and aligned with regard to their
removing the camshaft pulley. This easy-to-use axes.
tool is intended for all types of camshaft pulleys.

SKU L SKU
619723 525 1435 619730 211

2209

Alternator combination socket

2205
Piston ring compressor
› This two-part tool for the alternator allows
the easy dismounting and mounting of
the alternator pulley for the purposes of
pulley replacement or alternator repair. The
alternator is blocked by means of a 10 mm
XZN multispline insert; simultaneously, the
pulley retaining screw on the shaft is released/
tightened. The tool is available as a 1/2" socket
key with a XZN – M10 bit and as a 1/2" socket
key with a TX50 bit.

› use to install pistons on most passenger cars. SKU D L1 L2
› high quality construction with sprung steel 620225 M 10 23.8 113 75 178
wraps 620948 TX 50 23.8 113 75 176
› with safety adjusting screws
› available in a wide range of sizes
› This tool is used to install pistons and piston 1863
rings into engine cylinders. Di!erent sizes are

available. Universal kneeling and sitting pad
How to use the tool:
› Insert the piston and any piston rings into the
tool, position the tool at the opening and use it
to insert/push the piston and any piston rings
into the cylinder.

› material: low density
SKU H D" D polyethylene foam
619725 50 1 3/4" - 3 1/2" 40 - 90 178
619726 80 2 1/4"- 5" 57 - 125 291
619727 80 3 1/2" - 7" 90 - 175 320 SKU A B H
619729 165 3 1/2" - 7" 90 - 175 587 621982 500 219 30 95

306 OTHER WORKSHOP TOOLS
