1503 1506KZ7

Pneumatic !lter regulator and Coupling, female part
lubricator 3/4"

B › metal housing
› outside thread

SKU L
617793 R1/4" 20 58 98
› air inlet 3/4"
› maximum air pressure: 9,5 Bar 617794 R3/8" 20 54 101
› working pressure 0,5 - 8,5 Bar
› working temperature 5 - 60 °C 1506KZ10

› "ltering grade 5µ
› air consumption 2500 l/min Coupling, female part

› "lter capacity 60ml
› lubricator capacity 90ml

SKU L B
621473 190 240 1805 › metal housing
› outside thread
1505

Spiral pneumatic hose SKU L
621452 3/8" 24 62.5 149
621453 1/2" 24 65.0 156
621454 3/4" 27 67.1 191

1507Z7
Coupling, male part

› inside hose diameter Ø7mm
SKU L (m) D › outside thread
617743 9 1/4" 6.5 x 10 850 › metal housing
617744 9 1/4" 8 x 12 894
617745 9 3/8" 11 x 16 1526 SKU L
617746 12 1/4" 6.5 x 10 835 617797 R1/4" 14 34 24
617747 12 1/4" 8 x 12 1076 617798 R3/8" 19 36.5 34
617748 12 3/8" 11 x 16 1847 618483 R1/2" 22 39 40

1506KN7 1507Z10
Coupling, female part Coupling, male part

› outside thread
› inside hose diameter Ø10mm
› metal housing › metal housing
› inside thread

SKU L
SKU L 621455 3/8" 17 39.4 38
617795 R1/4" 20 54.5 113 621456 1/2" 24 39.4 53
617796 R3/8" 20 55 105 621457 3/4" 27 48.5 86
