P. 128

190VDEDP6P13B                       406/1VDEBI                          406/1VDEDP
       Insulated socket set 1/2" in metal box  Combination pliers              Combination pliers










                                           › material: premium plus carbon steel  › material: premium plus carbon steel
                                           › drop forged, entirely hardened and tempered  › drop forged, entirely hardened and tempered
                                           › cutting edges induction hardened  › cutting edges induction hardened
                                           › head polished                     › head polished
                                           › surface "nish: chrome plated to standard ISO   › surface "nish: chrome plated according to ISO


                                            1456:2009                            1456:2009
                                           › heavy duty double - component handles  › made according to standard ISO 5746 and EN
                                           › made according to standard ISO 5746 and EN   IEC 60900
                                            IEC 60900
                                                                               Advantages:
                                                                               › handles are insulated with double layered -
       › Dimension of box: 321 x 198 x 54                                        double coloured insulation for additional safety
       Set includes:                                                           Important!
       › 11x insulated socket 1/2", 6 point (article                           › if second layer is visible, replace your insulated
        190/2VDEDP) dim. 8, 10, 11, 12, 13, 14, 17, 19,                          tool with a new one.
        22, 24, 27                        SKU     L    B     C     A
       › 1x insulated reversible ratchet 1/2"
       › insulated accessories 1/2"; 1x extension bar   610421  160  24  35  9.5  224
        (125mm)                           610422  180  27    38    10   274
                                          610423  200  29    41   10.5  344
                                          610424  220  32    47    11   424
                                          cutting capacity (10N=1kg)
                                          SKU    L   max 1600 N/mm" ∅  max 650 N/mm" ∅
                                          610421  160    1,6         2,0
                                          610422  180    1,8         2,5
      SKU                                 610423  200    2,0         2,5      SKU     L     B    C     A
      619420         8 - 27         13    610424  220    2,0         3,0      619177  140   23   32    8    157
                                                                              619178  160   24   35    9.5  219
                                                                              619179  180   27   38    10   269
                                                                              619180  200   29   41   10.5  321
                                                                              619181  220   32   47    11   376
                                                                               cutting capacity (10N=1kg)
                                                                              SKU    L   max 1600 N/mm" ∅  max 650 N/mm" ∅
                                                                              619177  140    1,6         2,0
                                                                              619178  160    1,6         2,0
                                                                              619179  180    1,8         2,5
                                                                              619180  200    2,0         2,5
                                                                              619181  220    2,0         3,0

































      126                                 INSULATED TOOLS
